Hongfa Europe GMBH PCB Power Relay 24V DC Coil 10A Switching Current SPST HF118F/024-1ZS1T(136)

Hongfa Europe GMBH HF118F/024-1ZS1T(136) PCB Power Relay is a high performance, non-latching, single-pole single-throw (SPST) relay designed for use in various industrial and commercial applications. Featuring a 24V DC coil, it delivers reliable switching with a maximum current rating of 10A for both DC and AC circuits.

This power relay is designed for PCB mounting with PCB pin terminals, making it suitable for compact and automated circuit designs. The relay offers a coil resistance of 2.4kΩ and low coil power consumption at 290mW, optimizing energy efficiency in control circuits.

Constructed with silver alloy contact material, the device ensures low contact resistance (100 milliohms) and high electrical endurance, extending its operational life. It is capable of switching up to 125V DC and 440V AC voltages, withstanding isolation voltages up to 5KV and surge voltages up to 10KV, providing robust protection against electrical stress.

Operating within a wide temperature range from -40°C to 85°C, this relay supports demanding environments including automotive systems, industrial machinery, household appliances, and telecommunications equipment. Its compact size (28.5mm length, 12.5mm height, 10.1mm width) allows for excellent board space savings in electronics assemblies.

The product complies with RoHS environmental standards, ensuring it meets regulations for hazardous substance restrictions. It is manufactured in China and delivered new and ready for industrial use.

This power relay supports PCB mounting with standard PCB pin terminals. It operates within a temperature range from -40°C to 85°C ensuring durability under harsh conditions. Silver alloy contact material provides high electrical endurance and low contact resistance of 100 milliohms.

Offers a high isolation voltage of 5KV and can withstand surge voltages up to 10KV for robust performance. Its compact dimensions of 28.5mm length, 12.5mm height, and 10.1mm width suit efficient board space saving. Coil resistance is 2.4kΩ with coil power consumption at 290mW, facilitating low power operation.

This relay meets RoHS environmental standards, confirming eco-friendly manufacturing. Applicable across automotive, industrial machinery, telecommunication, and household appliances. Explore more Power Relay solutions and components at EnvMart for sophisticated industrial and electrical applications.
