Chauvin Arnoux AC Adapter Current Clamp 240 A Max, BNC Connector, Model P01120402

Chauvin Arnoux P01120402 is an AC adapter current clamp designed for precise AC current measurement with a maximum rating of 240 A. It features a BNC connector output and is suitable for use with most multimeters and recorders having a 200 mA AC range. The clamp supports conductor sizes up to 20 mm and is built to operate within temperatures from -10°C to 55°C.

The device is compliant with IEC1010-2-032 safety standard at 600 V CAT III, ensuring safe operation in demanding industrial environments. It uses LR6 alkaline AA batteries and includes a 1.5 m flying lead equipped with 4 mm shrouded plugs.

Its ergonomic jaw design enables convenient hooking onto cables even in confined spaces, facilitating accurate single or dual range current measurements. The output voltage limiter feature adds protection against potential damage when the clamp output is open circuited.

Applications include industrial electrical testing, laboratory measurements, HVAC current monitoring, manufacturing process control, and other electrical diagnostics. AC adapter type designed for current measurement. Maximum conductor size is 20 mm for versatile cable compatibility.

Accuracy of ±1% ensures reliable readings. Equipped with a 1.5 m cable length for convenient connection. BNC connector type fits standard multimeter inputs. Operates safely within -10°C to 55°C ambient temperature. Certified to IEC1010-2-032 safety standard and rated CAT III at 600 V.

Powered by LR6 alkaline AA batteries for reliable operation. Ergonomic jaw design enables measurement in difficult to access areas. Output voltage limiter protects multimeters by preventing high open-circuit voltages. Set includes the Chauvin Arnoux P01120402 Current Clamp with integral cable and connectors.

Explore more measuring and testing instruments from Chauvin Arnoux at EnvMart.
