Schneider Electric Surface Power Relay 120V AC Coil 12A Switching Current DPDT 750XBXH-120A
Specifications
| Country of Origin | China |
|---|---|
| Brand | Schneider Electric |
| Height | 36.6mm |
| Length | 40.9mm |
| Model | 750XBXH-120A |
| Width | 40.9mm |
| Mount Type | Surface |
| Contact Material | Silver Alloy |
| Series | 750X |
| Maximum Operating Temperature | 55°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 12A |
| Terminal type | Plug-In |
| Standards/Approvals | CSA, UL |
| Coil Resistance | 1.7kΩ |
| Coil Voltage | 120V ac |
| Switching AC Voltage | 300V ac |
| Coil Power | 1.2W |
Key Features
- The relay features a DPDT contact configuration enabling dual pole switching.
- Equipped with a 120V AC coil voltage suitable for standard control circuits.
- The maximum switching current of 12A supports medium power loads.
- Designed with a surface mounting type for easy installation on various panels.
- Coil resistance is precisely 1.7 kilo-ohms for consistent operation.
- Compact dimensions with a height of 36.6 mm, and width and length of 40.9 mm each.
- Contact material made of high-quality silver alloy ensuring durability and low resistance.
- Operating temperature range from -40°C to 55°C enables use in diverse environments.
Product Description
Schneider Electric 750XBXH-120A is a surface power relay with a 120V AC coil voltage and 12A switching current, featuring DPDT contact configuration ideal for industrial, automation, and control applications. Its compact design includes a height of 36.6 mm and a width and length of 40.9 mm each, making it suitable for integration in control panels and systems.
This 750X series relay provides reliable switching with a coil resistance of 1.7 kΩ and coil power consumption of 1.2 W to maintain energy efficiency. It is engineered for extended durability using silver alloy contact materials that reduce wear and contact resistance.
With a wide operating temperature range from -40°C to 55°C, it is suitable for varying environmental conditions. The plug-in terminal type facilitates easy installation and maintenance. It complies with international standards including CSA and UL, ensuring safety and regulatory adherence.
This relay is hermetically sealed and designed for hazardous locations, providing octal style mounting and options suitable for automation and control operations that require dependable switching up to 300V AC.
The relay's DPDT configuration supports switching two independent circuits simultaneously. It features a surface mount type that allows simple panel integration. The silver alloy contact material ensures low contact resistance and high reliability.
Compliance with CSA and UL standards guarantees trusted safety performance. Coil voltage of 120V AC and coil power of 1.2W are optimized for control circuit efficiency. Designed for use in industrial automation, HVAC controls, manufacturing equipment, and electrical control systems.
Package details and mounting options make the 750XBXH-120A relay suitable to engineers and technicians looking for a dependable power relay solution in demanding industrial environments. Explore more Schneider Electric Power Relay products on EnvMart for comprehensive control and automation solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage of this power relay is 120V AC, making it suitable for standard control circuits.
The maximum switching current for this model is 12A, which supports medium power loads.
This relay has a height of 36.6 mm and both a width and length of 40.9 mm each, making it compact for panel integration.
It features a DPDT (Double Pole Double Throw) contact configuration, allowing for the switching of two independent circuits simultaneously.
The coil resistance of this relay is 1.7 kΩ, which ensures consistent operation.
The operating temperature range for this model is from -40°C to 55°C, enabling its use in diverse environments.
The contacts are made of high-quality silver alloy, which ensures low contact resistance and high reliability.
This relay supports surface mounting, allowing for easy installation on various panels.
It complies with CSA and UL standards, ensuring safety and regulatory adherence.
The coil power consumption of this model is 1.2W, which is optimized for control circuit efficiency.
The maximum switching AC voltage for this relay is 300V AC, suitable for various applications.
This model features a plug-in terminal type, facilitating easy installation and maintenance.
