Microchip Operational Amplifier 5 MHz, 8-Pin MSOP, 3-6V Supply MCP6282-E/MS

Microchip's MCP6282-E/MS is a high-performance operational amplifier designed for surface mount technology applications. Operating with a low voltage supply range between 3 V and 6 V, it delivers a gain bandwidth product of 5 MHz, suitable for a broad spectrum of analog signal processing tasks.

Featuring two channels and housed in a compact 8-pin MSOP package measuring 3 mm by 3 mm with a height of 0.85 mm, this op amp fits efficiently on dense PCB layouts commonly found in industrial and commercial electronic devices.

Its exceptionally low input bias current of 1 picoampere and minimal input offset voltage of 5 millivolts ensure high signal fidelity, while a slew rate of 2.5 volts per microsecond accommodates rapid signal transitions. Moreover, the device operates reliably across a wide temperature range from -40°C to 125°C, making it suitable for automotive and industrial environments.

The amplifier can source output currents up to 25 milliamperes, enabling direct drive capability for various loads without the need for external buffering components. Compliance with RoHS standards guarantees the device adheres to environmental regulations and promotes safe usage.

Applications of the MCP6282-E/MS operational amplifier include precision amplification in instrumentation, sensor signal conditioning, industrial control systems, and general-purpose analog circuitry. Its robust specifications and compact package make it a versatile component for modern electronic designs.

Supports dual channels for versatile amplification requirements. Low input bias and offset currents enhance signal accuracy. High slew rate of 2.5 V/μs supports fast signal changes. Wide operating temperature range from -40°C to 125°C for industrial environments.

Compact MSOP package dimensions enable space-efficient PCB designs. Output current capability up to 25 mA for driving loads. RoHS compliant ensuring environmental safety and regulatory conformance. Ideal for precision analog signal conditioning in industrial and instrumentation circuits.
