Microchip Operational Amplifier 10 MHz 14-Pin Surface Mount TSSOP Package 3-5.5V MCP6024-I/ST
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 0.9mm |
| Length | 5mm |
| Model | MCP6024-I/ST |
| Width | 4.4mm |
| Mount Type | Surface |
| Series | MCP6024 |
| Output Current | 30mA |
| Maximum Operating Temperature | 85°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Standards/Approvals | RoHS |
| Pin Count | 14 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 10MHz |
| Input Bias Current | 1 pA |
| Slew Rate | 7V/μs |
Key Features
- Operates within supply voltage range from 3V to 5.5V for versatile power options.
- Four channels provide flexibility for multi-stage amplification.
- Slew rate of 7 V/μs ensures quick response and signal fidelity.
- Input offset voltage is low at 500 μV for precision analog signal processing.
- Compact TSSOP package with dimensions 5 mm length and 4.4 mm width suits space-constrained PCB designs.
- Wide operating temperature range from -40°C to 85°C enables reliable performance in harsh environments.
- Output current max 30 mA supports a variety of load conditions.
- RoHS compliant, ensuring environmentally friendly manufacturing standards.
Product Description
Microchip MCP6024-I/ST is a quad operational amplifier designed for precision analog signal applications. Featuring a gain bandwidth product (GBP) of 10 MHz, this device supports high-speed amplification while maintaining low noise and offset characteristics. Packaged in a 14-pin TSSOP surface mount package, its compact size with dimensions of 5 mm length, 4.4 mm width, and a height of 0.9 mm enables integration into dense PCB layouts.
The operational amplifier operates at low supply voltages ranging from 3 V minimum to a maximum of 5.5 V, making it suitable for battery-operated and low power systems. Its slew rate of 7 V/μs allows for fast signal transitions, and its input offset voltage of 500 μV ensures minimal signal distortion in precision measurement applications.
With the ability to drive output currents up to 30 mA, the MCP6024-I/ST can handle a range of load conditions commonly encountered in industrial, laboratory, telecommunications, and consumer electronics contexts. Its extended operating temperature range of -40°C to 85°C ensures stability and durability in harsh environmental conditions.
This model is RoHS compliant, meeting current environmental regulations by restricting hazardous substances. Typical applications include signal conditioning, active filtering, and amplifier configurations in semiconductor electronics.
Operates with a supply voltage range of 3 V to 5.5 V. Four independent amplifier channels in one package. Compact 14-pin TSSOP surface mount design for space-efficient PCB integration. Robust operating temperature range from industrial -40°C to 85°C.
High slew rate of 7 V/μs to support rapid signal changes. Low input offset voltage for accurate analog signal processing. Output current capability up to 30 mA for various load driving applications. Complies with RoHS environmental standards for sustainability.
Microchip Operational Amplifiers like the MCP6024-I/ST are essential components in semiconductor electronics widely used in industrial, laboratory, telecommunications, and consumer device applications. Discover more reliable semiconductor components by browsing related products at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This operational amplifier operates within a supply voltage range from 3 V to 5.5 V, making it suitable for various power options.
The MCP6024-I/ST features four independent amplifier channels in one package, providing flexibility for multi-stage amplification.
The gain bandwidth product of the MCP6024-I/ST is 10 MHz, supporting high-speed amplification while maintaining low noise characteristics.
It can drive output currents up to 30 mA, accommodating a variety of load conditions commonly encountered in different applications.
The slew rate of this model is 7 V/μs, allowing for fast signal transitions and maintaining signal fidelity.
The MCP6024-I/ST is packaged in a 14-pin TSSOP with dimensions of 5 mm in length, 4.4 mm in width, and a height of 0.9 mm.
It operates within an extended temperature range from -40°C to 85°C, ensuring reliable performance in harsh environments.
Yes, this operational amplifier is RoHS compliant, adhering to environmental regulations by restricting hazardous substances.
The input offset voltage is low at 500 μV, which is beneficial for precision analog signal processing.
Typical applications include signal conditioning, active filtering, and amplifier configurations in semiconductor electronics.
The MCP6024-I/ST uses a surface mount type, suitable for space-constrained PCB designs.
The input bias current for the MCP6024-I/ST is 1 pA, which contributes to its precision in analog applications.
