KEMET SPST Through Hole Reed Switch 100 mA 30 V dc OHD5R-130B

KEMET OHD5R-130B SPST Through Hole Reed Switch is engineered for precise switching performance in low current and voltage circuits, with a maximum switching current of 100 mA and voltage rating up to 30 V dc.

This Reed Switch uses a single pole single throw (SPST) contact configuration featuring Nickel Iron Alloy contacts known for their high reliability and durability under electrical load.

Designed with through hole wire terminals, it enables straightforward mounting on printed circuit boards (PCBs) for various industrial and electronic applications.

The switch operates effectively within a wide temperature span from -20°C to 150°C, making it suitable for diverse environmental conditions. Compact size dimensions (5 mm width, 6.7 mm length, and 19.1 mm depth) allow installation in space-constrained assemblies.

The OHD Thermal Guard series integrates Thermorite®, a temperature sensing soft ferromagnetic material with magnetic flux density that decreases with rising temperature, ensuring stable operation even in thermal critical applications.

Single pole, single throw contact configuration. Maximum switching current: 100 mA. Maximum switching power: 1 W. Maximum switching voltage: 30 V dc. Contact resistance of 300 mΩ. Nickel Iron Alloy contacts for longevity.

Through hole mounting with wire terminals. Wide operating temperature range from -20°C to 150°C. Compact physical dimensions suitable for PCB assemblies. RoHS compliant for environmental safety.

Typical applications include temperature detection and thermal monitoring in power transistors, modules, motors, heaters, amplifiers, HDDs, and other general appliances in industrial, HVAC, manufacturing, and electronics sectors.
