KEMET SPST Through Hole Reed Switch 100 mA 30 V dc OHD5R-50B

KEMET OHD5R-50B SPST Through Hole Reed Switch is a precision component designed for switching applications with a maximum switching current of 100 mA and voltage rating up to 30 V dc. It is engineered to provide high reliability and long operational life in industrial, electronic, and automation systems.

This switch employs a single-pole single-throw (SPST) contact configuration fabricated with nickel iron alloy, delivering excellent electrical contact quality with a low resistance of 300 milliohms. The wire terminal type and through hole mount ensure stable and robust integration onto PCBs.

Its compact form factor of 5 mm width, 6.7 mm length, and 19.1 mm depth allows it to fit within dense electronic assemblies while maintaining performance standards. The device meets RoHS compliance, underlining its environmental compatibility and safe use in green manufacturing processes.

Designed under the OHD Thermal Guard series, it features thermal reliability by incorporating Thermorite®, a temperature-sensitive ferromagnetic material that enhances operations by adapting to thermal changes. This makes the switch ideal for applications requiring atmospheric temperature detection and overheating monitoring, such as power transistors, power modules, motors, amplifiers, and general household and industrial appliances.

Utilizes SPST contact configuration for precise control. Maximum switching current and voltage set to 100 mA and 30 V dc respectively. Low contact resistance ensures dependable electrical connections. Nickel iron alloy contacts provide durability and stable operation.

Through hole mounting with wire terminals allows secure PCB installation. Wide ambient operating temperature range from -20°C to 150°C. Compact size supports integration in various electronic assemblies. RoHS compliant for environmentally friendly applications.

OHD Thermal Guard series ensures thermal problem countermeasure capability. Manufactured in Japan, guaranteeing quality and reliability.

This Reed Switch suits diverse industrial sectors including Electronics, Automation, HVAC systems, and general manufacturing uses requiring reliable switching with thermal sensitivity.
