CIF 1 Matrix Board FR2 1 mm Holes, 2.54 mm Pitch, 100 mm x 100 mm ACP16
Specifications
| Country of Origin | France |
|---|---|
| Brand | CIF |
| Length | 100mm |
| Model | ACP16 |
| Width | 100mm |
| Hole Diameter | 1mm |
| Board Material | Bakelite |
| Standards/Approvals | BS EN 61340, ANSI/ESD S20 |
| Number of Sides | 1 |
| Board Thickness | 1.5mm |
| FR Material Grade | FR2 |
| Hole Pitch | 2.54mm |
| Copper Thickness | 35μm |
| RS PRO 1 Matrix Board FR2 With 34 x 64 1.02 mm Holes, 160 mm 100mmRS Stock No. | 100-4340Brand: RS PRO |
Key Features
- This matrix board is single-sided for efficient circuit prototyping.
- The FR2 grade bakelite board ensures good insulation and durability.
- Holes are 1 mm in diameter and spaced with a 2.54 mm pitch for standard component mounting.
- Copper thickness of 35 micrometers with 15/10th tinned copper clad pads enhances conductivity.
- Board thickness measures 1.5 mm providing rigidity to the board.
- Square pads are 2 mm on each side, ensuring secure soldering points.
- Conforms to standards BS EN 61340 and ANSI/ESD S20 for ESD protection.
- Ideal for laying out electrical components and custom circuit board fabrication.
Product Description
CIF ACP16 1 Matrix Board FR2 is a high-quality single-sided prototyping board measuring 100 mm in length and width with a thickness of 1.5 mm. It features 1 mm diameter holes spaced at a 2.54 mm pitch allowing for standardized component placement.
Constructed from durable bakelite with FR2 flame retardant grade material, it provides excellent electrical insulation suitable for various electronic prototyping tasks. The board incorporates 15/10th tinned copper clad pads with a copper thickness of 35 micrometers, delivering reliable conductivity for soldered connections.
Square copper pads, each 2 mm per side, are precisely aligned across the board enabling secure placement and soldering of components. This matrix board meets strict standards including BS EN 61340 and ANSI/ESD S20, ensuring adequate electrostatic discharge (ESD) protection for sensitive electronics.
Key applications for this matrix board include use as a pre-design tool for circuit layouts, securely mounting electronic components, and customizing circuit fabrication processes in laboratory, industrial, manufacturing, and educational environments.
This Matrix Board is single-sided for efficient circuit prototyping. The FR2 grade bakelite board ensures good insulation and durability. Holes are 1 mm in diameter and spaced with a 2.54 mm pitch for standard component mounting.
Copper thickness of 35 micrometers with 15/10th tinned copper clad pads enhances conductivity. Board thickness measures 1.5 mm providing rigidity to the board. Square pads are 2 mm on each side, ensuring secure soldering points.
Conforms to standards BS EN 61340 and ANSI/ESD S20 for ESD protection. Ideal for laying out electrical components and custom circuit board fabrication. Manufactured in France ensuring quality and compliance.
This product is part of the Electronics & Electricals category, specifically under Electronics Components and Prototyping Boards. Explore our full range of electronic prototyping solutions at EnvMart for reliable and precise circuit development needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The matrix board measures 100 mm in length and 100 mm in width, with a thickness of 1.5 mm.
It features holes with a diameter of 1 mm, spaced at a 2.54 mm pitch.
The board is constructed from bakelite, specifically FR2 grade, which provides good insulation and durability.
The copper thickness is 35 micrometers, with 15/10th tinned copper clad pads to enhance conductivity.
It conforms to the standards BS EN 61340 and ANSI/ESD S20 for electrostatic discharge (ESD) protection.
This model is single-sided, which is suitable for efficient circuit prototyping.
The square pads measure 2 mm on each side, providing secure soldering points for components.
It is ideal for laying out electrical components, custom circuit board fabrication, and use in laboratory, industrial, manufacturing, and educational environments.
This product is manufactured in France, ensuring quality and compliance with relevant standards.
The FR2 material grade provides flame retardant properties, enhancing safety during electronic prototyping.
It serves as a pre-design tool for circuit layouts and securely mounts electronic components for prototyping.
The product description does not specify any included accessories; it is focused on the matrix board itself.
