Littelfuse 0.75 A Resettable Fuse 13.2V DC PolySwitch Mini SMDC Series MINISMDC075F-2
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 13.2V dc |
| Brand | Littelfuse |
| Height | 0.62mm |
| Length | 4.73mm |
| Model | MINISMDC075F-2 |
| Width | 3.41mm |
| Current Rating | 750mA |
| Series | PolySwitch |
| Maximum Operating Temperature | 85°C |
| Trip Current | 1.5A |
| Power Dissipation | 1W |
| Terminal Material | Tin Plated |
| Time to Trip | 0.2s |
| Hold Current | 0.75A |
| Minimum Resistance | 0.11Ω |
| Maximum Resistance | 450mΩ |
| SMDC series resettable mini fuse,0.75ABrand | TE Connectivity |
Key Features
- This fuse rapidly switches from low to high resistance under overload, protecting circuits efficiently.
- Small size with length 4.73mm, width 3.41mm, and height 0.62mm facilitates compact surface mount design.
- Features automatic reset capability for thousands of cycles, reducing maintenance needs.
- Constructed with tin-plated terminals and halogen-free materials for reliability and environmental safety.
- Power dissipation rating of 1 watt ensures safe operation within electrical limits.
- Maximum operating temperature of 85°C supports diverse electronic applications.
- Typical applications include security systems, power supplies, automotive devices, instrumentation, and computing peripherals.
Product Description
Littelfuse MINISMDC075F-2 resettable fuse is a PolySwitch Mini SMDC series surface mount device designed for effective circuit protection in various electronic systems.
Operating at 0.75 amp hold current and maximum trip current of 1.5 amp, with a rapid trip time of 0.2 seconds, this fuse safeguards against electrical overloads and short circuits by automatically switching to a high resistance state.
Its compact dimensions (4.73mm length, 3.41mm width, 0.62mm height) and tin-plated terminal material support easy integration onto printed circuit boards without requiring fuse holders.
Constructed with halogen-free materials and compliant with RoHS standards, it ensures environmental compliance and long-term reliability. Power dissipation is rated at 1 watt and maximum operating temperature is 85°C, suitable for various industrial, automotive, computing, and instrumentation use cases.
This fuse allows automatic resetting thousands of cycles, reducing downtime and maintenance efforts in consumer electronics, multimedia, automotive, audio-visual, telecommunications, power switching devices, and medical equipment circuits.
This fuse rapidly switches from low resistance to high resistance under electrical overloads, providing fast and effective circuit protection. Compact surface mount design enables space saving on PCBs with no need for fuse holders.
Automatic reset feature allows maintenance-free protection for thousands of trip cycles. Constructed from halogen-free materials for environmental safety. Rated for up to 1 watt power dissipation and 85°C operating temperature for robust performance.
Suitable for applications in security systems, power supplies, automotive electronics, instrumentation, computers, and telecommunications. PolySwitch series ensures reliable, long-lasting circuit protection in multiple industrial and commercial environments.
Explore more Littelfuse Resettable Fuses and PolySwitch products at EnvMart for enhanced circuit protection solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The hold current rating of this resettable fuse is 0.75 A.
The maximum trip current for this model is 1.5 A.
This fuse has dimensions of 4.73 mm in length, 3.41 mm in width, and 0.62 mm in height.
The voltage rating for this resettable fuse is 13.2 V DC.
The time to trip for this fuse is 0.2 seconds.
The power dissipation rating of this resettable fuse is 1 watt.
The terminals of this fuse are constructed from tin-plated material.
The maximum operating temperature for this resettable fuse is 85°C.
This fuse features an automatic reset capability that allows it to reset after tripping, enabling maintenance-free protection for thousands of cycles.
Typical applications for this fuse include security systems, power supplies, automotive devices, instrumentation, and computing peripherals.
The minimum resistance is 0.11 Ω and the maximum resistance is 450 mΩ.
Yes, this fuse is constructed with halogen-free materials and complies with RoHS standards for environmental safety.
