Eaton DILMT Contactor 3-Pole 95 A 45 kW 24V AC Coil, 3 NO, 660V 197623 DILMT95(24V50/60HZ)
Specifications
| Country of Origin | India |
|---|---|
| Brand | Eaton |
| Function | Motor Control |
| Length | 112mm |
| Model | 197623 DILMT95(24V50/60HZ) |
| Depth | 125mm |
| Width | 72mm |
| Mount Type | DIN Rail |
| Series | DILMT |
| Power Rating | 45kW |
| Maximum Operating Temperature | 55°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Screw |
| Number of Poles | 3 |
| Standards/Approvals | CSA, IEC, UL |
| Contact Voltage | 660V |
| Coil Voltage | 24V ac |
| Normal State Configuration | 3 NO |
| Contact Current | 95A |
| Operational Current Ie | 95A |
| Control Circuit Voltage Uc | 24V ac |
| Contactor Application | Motor Control |
| Pole and Throw Configuration | 3 |
Key Features
- Operates with a 24V AC coil voltage for efficient control.
- Features 3 poles with 3 Normally Open (NO) contacts configuration.
- Supports contact current up to 95 A and contact voltage up to 660V.
- Includes screw terminal type for secure electrical connections.
- Designed for DIN rail mounting with compact dimensions.
- Utilization category AC-1 for non-inductive or slightly inductive loads.
- Wide operating temperature range from -25°C to 55°C.
- Meets CSA, IEC, and UL safety standards.
Product Description
Eaton 197623 DILMT95(24V50/60HZ) Contactor is a high-performance 3-pole electrical device with a 24V AC coil designed for motor control applications. It is engineered to handle operational currents of 95 A at contact voltages up to 660V and power ratings of 45 kW, making it ideal for industrial motor switching tasks.
The contactor supports a normally open contact configuration with 3 NO contacts and features screw-type electrical connections for the main circuit, ensuring secure and reliable wiring. Its construction suits DIN rail mounting installations with compact dimensions of 112mm length, 72mm width, and 125mm depth, enabling ease of integration into electrical control panels.
This model operates efficiently over a wide temperature range from -25°C to 55°C and complies with stringent CSA, IEC, and UL safety standards. The utilization category AC-1 indicates suitability for non-inductive or slightly inductive loads and resistance furnaces, while NAC-3 rating extends its applicability to standard AC induction motors.
The contactor is designed for 50 to 60 Hz AC operation and offers a broad storage temperature range of -40 to 80°C, ensuring durability in demanding environments. This robust contactor also features the former Moeller brand heritage under Eaton, reflecting legacy quality and reliability.
Operates with a 24V AC coil voltage for efficient control. Features 3 poles with 3 Normally Open (NO) contacts configuration. Supports contact current up to 95 A and contact voltage up to 660V. Includes screw terminal type for secure electrical connections.
Designed for DIN rail mounting with compact dimensions. Utilization category AC-1 for non-inductive or slightly inductive loads. Wide operating temperature range from -25°C to 55°C. Meets CSA, IEC, and UL safety standards.
Suitable for motor control applications. Formerly known as Moeller brand contactors by Eaton.
This contactor is suitable for industrial, commercial, and manufacturing motor control applications requiring reliable switching. Its DIN rail mounting and screw terminal design facilitate installation and maintenance in control cabinets and automation panels.
Discover more products like Eaton Contactors and other electrical control gear to optimize your industrial automation solutions on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Eaton DILMT Contactor has a power rating of 45 kW.
This contactor supports a maximum contact voltage of 660V.
The DILMT95 can handle a contact current of up to 95 A.
It is designed for DIN rail mounting, allowing for easy integration into electrical control panels.
The dimensions are 112mm in length, 72mm in width, and 125mm in depth.
The coil voltage for this model is 24V AC.
It operates efficiently within a temperature range of -25°C to 55°C.
It includes screw terminal type connections for secure wiring.
This contactor meets CSA, IEC, and UL safety standards.
The contactor features a normal state configuration of 3 Normally Open (NO) contacts.
It is suitable for motor control applications, particularly for non-inductive or slightly inductive loads.
The minimum storage temperature for this contactor is -40°C.
