WEG CWC Contactor, 24V AC Coil, 3-Pole, 9 A, 4 kW Power, 3 NO Contacts, 690V AC CWC09-10-30D02

Free Delivery in India | Lowest Global Shipping Charges

WEG CWC Contactor, 24V AC Coil, 3-Pole, 9 A, 4 kW Power, 3 NO Contacts, 690V AC CWC09-10-30D02



Category Contactor Brand WEG Condition New

Specifications

Country of Origin	Brazil
Brand	WEG
Function	Motor Control
Length	58mm
Model	CWC09-10-30D02
Depth	52mm
Width	45mm
Mount Type	DIN Rail
Series	CWC
Power Rating	4kW
Maximum Operating Temperature	55°C
Minimum Operating Temperature	-25°C
Terminal type	Screw
Number of Poles	3
Standards/Approvals	IEC, RoHS, UL
Contact Voltage	690V ac
Coil Voltage	24V ac
Normal State Configuration	3 NO
Contact Current	9A
Number of Auxiliary Contacts	1
Auxiliary Contact Configuration	1 NO
Operational Current Ie	9A
Control Circuit Voltage Uc	24V ac
Contactor Application	Motor Control
Pole and Throw Configuration	3PST

Key Features

Operates on 24V AC coil voltage for efficient switching.
Supports 3 poles with 9A contact current capacity.
Power rating of 4 kW suitable for various industrial motors.
Features 3 normally open (NO) contacts for reliable operation.
Designed for DIN Rail mounting ensuring easy installation.
Equipped with one auxiliary contact with 1 NO configuration.
Constructed with screw terminals for secure wiring connections.
Operational temperature range from -25°C to 55°C for diverse environments.

Product Description

The WEG CWC09-10-30D02 is a professional-grade contactor with a 24V AC coil voltage, designed specifically for motor control in industrial and commercial applications.

This 3-pole contactor supports a contact current of 9A and a power rating of 4 kW, making it ideal for efficient switching of electric motors. It features a robust and compact design with a set of 3 normally open contacts to ensure reliable and safe operation.

Equipped with screw terminals, the contactor provides secure wiring connections. The unit also includes one auxiliary contact configured as 1 NO to support control circuits and feedback functions. Its construction adheres to IEC, RoHS, and UL standards, ensuring compliance with international quality and safety regulations.

Designed for ease of installation, the contactor mounts easily on DIN rails or panels. Its operational temperature range of -25°C to 55°C allows it to function in a wide variety of industrial environments.

With compact dimensions (58mm length, 45mm width, and 52mm depth) and a pole and throw configuration of 3 PST, it fits neatly into control panels without occupying excessive space.

Manufactured in Brazil, this WEG contactor is part of the CWC series, known for high reliability and performance in switching electric motors. It is widely used in automation, manufacturing, HVAC systems, and other industrial motor control applications.

Operates on 24V AC coil voltage for efficient switching. Supports 3 poles with 9A contact current capacity. Power rating of 4 kW suitable for various industrial motors. Features 3 normally open (NO) contacts for reliable operation.

Designed for DIN Rail mounting ensuring easy installation. Equipped with one auxiliary contact with 1 NO configuration. Constructed with screw terminals for secure wiring connections. Operational temperature range from -25°C to 55°C for diverse environments.

Compact dimensions: Length 58mm, Width 45mm, Depth 52mm. Built according to IEC, RoHS, and UL standards for quality assurance. Explore more high-quality Contactors and automation products in the Electronics & Electricals section on EnvMart for your industrial control and automation needs.
