Megger AC/DC Clamp Meter 600 A, 600 V, 35mm Jaw Capacity DCM340

Free Delivery in India | Lowest Global Shipping Charges

Megger AC/DC Clamp Meter 600 A, 600 V, 35mm Jaw Capacity DCM340

Name: Megger AC/DC Clamp Meter 600 A, 600 V, 35mm Jaw Capacity DCM340
Brand: Megger
SKU: 303755
Price: 377.73 USD
Availability: InStock



Category Clamp Meter Brand Megger Condition New

Specifications

Country of Origin	Taiwan
Display Type	LCD
Brand	Megger
Battery Life	200h
Battery type	Alkaline
Height	237mm
Length	68mm
Model	DCM340
Gross Weight	225g
Width	42mm
Maximum Operating Temperature	50°C
Minimum Operating Temperature	0°C
DC Current Accuracy	±1.9% ±10 Digits
DC Voltage Resolution	0 to 600 V dc
Resistance Measurement Accuracy	±1 % rdg + 3 Digits
Temperature Measurement Accuracy	80 %
AC Current Accuracy	±2.9% ±5 Digits
Resistance Resolution	400Ω
Maximum Jaw Opening	35mm
Standards/Approvals	RoHS
Functions Measured	DC Current, AC Current
Maximum Resistance Measurement	400Ω
Maximum DC Voltage Measurement	600V dc
Maximum DC Current Measurement	600A
Maximum AC Voltage Measurement	600V ac
Safety Category Level	CAT III
Safety Category Voltage	600V
Maximum Conductor Size	35mm
Clamp Meter Type	AC/DC Clamp Meter

Key Features

Measures AC and DC current and voltage with precise accuracy.
Features a 35mm jaw opening for accommodating various conductor sizes.
Includes a non-contact voltage detector for enhanced safety.
Lightweight design of 225g for comfortable handheld use.
Equipped with a high-resolution LCD display for clear readings.
Powered by an alkaline 9V battery with up to 200 hours battery life.
Automatic power-off function conserves battery life after 30 minutes of inactivity.
CAT III safety rating suitable for up to 600V environments.

Product Description

Megger DCM340 AC/DC Clamp Meter is a precision electrical measuring instrument designed for industrial, laboratory, HVAC, and electrical maintenance use. This device measures AC and DC current up to 600 A and voltage up to 600 V with high accuracy, featuring an easy-to-use 35mm jaw clamp suitable for small and large cables.

The incorporated non-contact voltage detector enables safe identification of live conductors, reducing risk during measurement tasks. It employs an alkaline 9V battery enabling extended operation of up to 200 hours, with an automatic power-off to save battery power after inactivity.

The LCD display provides clear and detailed measurements including resistance and continuity testing, making it an all-in-one solution for electrical diagnostics. Weighing only 225 grams, it offers ergonomic handling during long use and complies with RoHS standards ensuring environmentally safe construction.

Applications span installation, maintenance, monitoring, and fault finding in electrical systems where precise current and voltage assessment is critical. Measures AC and DC current and voltage with precise accuracy. Features a 35mm jaw opening for accommodating various conductor sizes.

Includes a non-contact voltage detector for enhanced safety. Lightweight design of 225g for comfortable handheld use. Equipped with a high-resolution LCD display for clear readings. Powered by an alkaline 9V battery with up to 200 hours battery life.

Automatic power-off function conserves battery life after 30 minutes of inactivity. CAT III safety rating suitable for up to 600V environments. Robust construction complies with RoHS standards.

This Clamp Meter is ideal for electricians, technicians, and engineers requiring reliable measurements in both industrial and commercial electrical environments. Explore more Megger measuring instruments on EnvMart for comprehensive electrical testing solutions.
