Siemens Inverter Drive SINAMICS G115D Series 1.5 kW 3 Phase 480V Panel Mount 6SL3520-3XB01-5AF0

Free Delivery in India | Lowest Global Shipping Charges

Siemens Inverter Drive SINAMICS G115D Series 1.5 kW 3 Phase 480V Panel Mount 6SL3520-3XB01-5AF0

Name: Siemens Inverter Drive SINAMICS G115D Series 1.5 kW 3 Phase 480V Panel Mount 6SL3520-3XB01-5AF0
Brand: Siemens
SKU: 298396
Price: 2982.78 USD
Availability: InStock



Category Inverter Drive Brand Siemens Condition New

Specifications

Country of Origin	United Kingdom
Brand	Siemens
Model	6SL3520-3XB01-5AF0
IP Rating	IP66, IP65
Mount Type	Panel
Series	SINAMICS G115D
Overall Width	380mm
Power Rating	1.5kW
Maximum Operating Temperature	55°C
Output Frequency	550Hz
Minimum Operating Temperature	-30°C
Number of Phases	3
Maximum Output Current	6.2A
Standards/Approvals	SEMI F47, REACH, KCC, EAC, C-Tick (RCM), CE
Maximum Supply Voltage	480V
Overall Depth	129mm
Minimum Supply Voltage	380V
Better World Claim	Saves Energy

Key Features

Delivers 1.5 kW power with a maximum output current of 6.2 A at 3-phase supply.
Supports supply voltages from 380V to 480V for flexible industrial applications.
Equipped with IP66 and IP65 ratings ensuring protection in harsh environments.
Operates over wide temperature range from -30°C to 55°C for diverse conditions.
Includes advanced vector control for conveyor systems and motor efficiency optimization.
Integrated safety features like STO safe torque off and fail-safe digital inputs.
Compact panel mount design with overall dimensions of 380mm width and 129mm depth.
Complies with key international standards including SEMI F47, REACH, KCC, EAC, and CE.

Product Description

Siemens 6SL3520-3XB01-5AF0 inverter drive from the SINAMICS G115D series is a robust industrial motor control solution rated at 1.5 kW and designed for 3-phase electrical systems with supply voltage ranging between 380V and 480V. This panel mount device is engineered to meet the demanding requirements of horizontal conveyor applications, providing precise encoderless vector control for asynchronous and synchronous reluctance motors of high efficiency.

The drive supports a maximum output current of 6.2 A and offers improved operational safety with integrated STO (Safe Torque Off) functions and fail-safe digital inputs compliant with PROFIsafe protocols. Robust ingress protection with IP66 and IP65 ratings ensures reliable operation in harsh industrial environments, while a wide operating temperature range from -30°C to 55°C guarantees performance stability across diverse conditions.

Its modular design allows for easy installation with no requirement for additional control cabinets, minimizing required space and cooling needs. Overall dimensions of 380mm width and 129mm depth facilitate integration into compact automation and control schemes.

Certified to international standards including SEMI F47, REACH, KCC, EAC, C-Tick (RCM), and CE, this inverter drive meets strict quality and environmental compliance. Manufactured in the United Kingdom, it supports Siemens SIMOGEAR 2KJ8 geared motors as part of complete drive systems.

Power rating of 1.5 kW suitable for moderate industrial loads. Three-phase operation ensures compatibility with standard industrial power supplies. IP66 and IP65 ratings for high ingress protection. Wide temperature tolerance for diverse industrial environments.

Integrated safety and fail-safe features for operational reliability. Compact panel mount design reduces system footprint. Standards compliance ensures safety and environmental responsibility.

This Siemens SINAMICS G115D Inverter Drive is suitable for a broad range of industrial, manufacturing, HVAC, and conveyor system applications demanding efficiency, reliability, and operational safety. Explore more automation and control gear options in the EnvMart industrial catalog to optimize your system setup.
