Eaton Residual Current Circuit Breaker PXF-A Series 25A 1-Pole 300mA Type A 500A 230V AC 236746 PXF-25/2/03-A

Eaton 236746 PXF-25/2/03-A Residual Current Circuit Breaker from the PXF-A Series is engineered for superior electrical protection in commercial and residential environments. Operating at 230V AC, it offers a current rating of 25A with a 1-pole configuration designed to detect residual currents with a trip sensitivity of 300mA. This Type A RCCB is also effective against pulsating direct currents up to 6 mA, enhancing safety against electric shocks and earth leakage faults.

The breaker is designed with a DIN Rail mount type and quick-connect terminals, facilitating straightforward installation and maintenance. Its compact size with dimensions of 80mm height, 45mm depth, and 35mm width allows for efficient use of panel space in electrical distribution boards.

This RCCB features a breaking capacity of 500A and instantaneous break time for rapid interruption of fault currents. The lever reset actuator ensures ease of manual operation after tripping events. Eaton’s PXF-A Series complies with IEC/EN 61008 standards and RoHS directives, guaranteeing high performance and environmental compliance. Manufactured in Serbia, it represents a blend of reliability and international manufacturing standards.

This Residual Current Circuit Breaker protects users from electric shock by disconnecting the power supply automatically in fault conditions. Type A devices are suitable for systems with alternating and pulsating direct currents, providing versatile protection.

Compatible with Eaton P-Series devices for contour and busbar mounting. Incorporates features such as fault current proof capability up to 250 A, double terminal connections, and retrofittable auxiliary switches. Displays real contact position and triggered state via signal contact for diagnostic convenience.

Ideal for commercial and residential electrical installations requiring reliable earth leakage protection. Explore Eaton products and PXF-A Series RCCBs on EnvMart for high-quality electrical protection solutions tailored to your application needs.
