ABB Residual Current Circuit Breaker 25A, 4-Pole, 30mA, Type A, 1kA, 277V AC F200 Series 2CSF204401R1250 F204 A-25/0,03 AP-R

ABB 2CSF204401R1250 F204 A-25/0,03 AP-R Residual Current Circuit Breaker is part of the F200 Series, engineered for comprehensive protection against earth leakage faults in electrical systems. With a current rating of 25A and a four-pole configuration, it is ideal for high-reliability circuit isolation in commercial and industrial environments.

This RCCB features a trip sensitivity of 30mA, the optimal threshold for detecting current leakage that could pose risk to personnel or equipment. Its Type A tripping characteristics enable protection against both alternating and pulsating direct currents, making it versatile for various load types and fault scenarios. The electromagnetic tripping mechanism ensures fast, instantaneous response to faults, effectively minimizing damage and hazard by immediately disconnecting the circuit.

The device supports 1kA breaking capacity and operates at a rated AC voltage of 277V, dealing with demanding operational requirements. It mounts easily onto DIN rails, and connection is managed via robust screw terminals. Users can reset the device using its toggle switch actuator, designed for ergonomic use and quick recovery after a protection event.

Its compact enclosure dimensions - 85mm in height, 69mm in depth, and 70mm in width - make it suitable for space-efficient electrical panels. Compliance with IEC EN 61008, CE, and RoHS standards ensures suitability for regulated environments, including industrial, laboratory, and commercial installations.

This ABB F200 Series RCCB serves applications ranging from building distribution networks to HVAC, manufacturing, and laboratory safety. The AP-R earth leakage protection type and reliable break time ensure both equipment and personnel are shielded against dangerous ground faults. Its configuration pairs well with automation panels and power distribution boards utilized across residential, industrial, and commercial settings.

Provides reliable earth leakage protection for electrical installations. Rated at 25A with four poles for enhanced safety and isolation. Features a 30mA trip sensitivity for effective current leakage detection. Type A tripping characteristics support both AC and pulsating DC fault currents.

Electromagnetic mechanism enables instantaneous break time. Designed for convenient DIN rail mounting with screw terminals. Reset actuator operated by a toggle switch for quick restoration. Compact housing: 85mm height, 69mm depth, and 70mm width.

Certified to IEC EN 61008, RoHS, and CE standards for compliance. Suitable for commercial, industrial, and domestic protection applications. Explore more ABB circuit protection solutions in the Residual Current Circuit Breaker category on EnvMart.
