ABB F200 Series Residual Current Circuit Breaker 63A 4-Pole 300mA Type A 1kA 480V AC 2CSF204201R3630 F204 A S-63/0,3

Free Delivery in India | Lowest Global Shipping Charges

ABB F200 Series Residual Current Circuit Breaker 63A 4-Pole 300mA Type A 1kA 480V AC 2CSF204201R3630 F204 A S-63/0,3



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	F200
Brand	ABB
Height	85mm
Model	2CSF204201R3630 F204 A S-63/0,3
Depth	69mm
Width	70mm
Mount Type	DIN Rail
Current Rating	63A
Series	F200
Terminal type	Screw
Breaking Capacity	1kA
Number of Poles	4
Standards/Approvals	CE, IEC EN 61008, RoHS
Rated AC Voltage	480V ac
Tripping Characteristics	Type A
Tripping Mechanism	Electromagnetic
Reset Actuator Type	Toggle Switch
Trip Sensitivity	300mA
Break Time	Instantaneous
Earth Leakage Protection Type	Type A

Key Features

Designed for DIN rail mounting ensuring easy installation.
Trip sensitivity is 300 mA, suitable for Type A tripping characteristics.
Breaking capacity of 1 kA supports reliable fault interruption.
Equipped with a toggle switch reset actuator for user convenience.
Supports rated AC voltage of 480V AC with instantaneous break time for rapid response.
Screw terminal type offers secure connections.
Compact dimensions of 85mm height, 69mm depth, and 70mm width optimize panel space.
Manufactured to comply with CE, IEC EN 61008, and RoHS standards for safety and environmental compliance.

Product Description

ABB 2CSF204201R3630 F204 A S-63/0,3 Residual Current Circuit Breaker is engineered for protecting electrical installations and personnel by detecting earth leakage currents with a nominal current rating of 63 amperes and four poles.

This model belongs to the F200 series, which offers both instantaneous and selective AC and Type A tripping characteristics to suit varied industrial and commercial applications.

It operates at a trip sensitivity of 300 mA with an instantaneous break time, ensuring prompt disconnection to prevent hazards. The breaker supports a rated AC voltage of 480V AC and a breaking capacity of 1 kA, making it suitable for medium power distribution panels.

The device features a toggle switch reset actuator and screw type terminals, facilitating easy operation and reliable electrical connections. Its compact form factor measures 85 mm in height, 69 mm in depth, and 70 mm in width, allowing efficient use of space in electrical enclosures.

Manufactured in Italy, it complies with international safety standards including CE certification, IEC EN 61008, and RoHS, ensuring compliance for industrial, commercial, and residential electrical safety requirements.

Designed for DIN rail mounting ensuring easy installation. Trip sensitivity is 300 mA, suitable for Type A tripping characteristics. Breaking capacity of 1 kA supports reliable fault interruption. Equipped with a toggle switch reset actuator for user convenience.

Supports rated AC voltage of 480V AC with instantaneous break time for rapid response. Screw terminal type offers secure connections. Compact dimensions of 85mm height, 69mm depth, and 70mm width optimize panel space. Manufactured to comply with CE, IEC EN 61008, and RoHS standards for safety and environmental compliance.

This Residual Current Circuit Breaker is ideal for industrial electrical panels, commercial installations, and safety applications within electrical distribution and automation systems. Its robust construction and adherence to key electrical standards make it a trustworthy choice for protecting circuits from earth faults, preventing electric shock, and reducing fire risk.
