ABB FH200 Series Residual Current Circuit Breaker 63A 4-Pole 30mA Type AC 1kA 400V AC FH200

ABB FH200 Residual Current Circuit Breaker (model FH200) is engineered for high-performance protection against earth fault currents in residential and industrial electrical installations. This device ensures safety by rapidly disconnecting circuits in the event of earth leakage currents using sensitive and reliable trip technology.

The breaker features a rated current capacity of 63 amperes and includes 4 poles to provide enhanced coordination and protection for multi-phase circuits. With a trip sensitivity of 30 milliamperes, it effectively detects low-level earth leakage currents, suitable for standard AC type applications.

Operational voltage rating is set at 400 volts alternating current, ensuring compatibility with common power distribution networks. The tripping characteristics are type AC, employing an instantaneous electromagnetic trip mechanism which guarantees fast fault clearance to minimize damage and risk.

Designed for ease of installation, the FH200 series mounts onto a DIN rail and uses screw terminals that provide a secure and reliable electrical connection. Its compact form factor measures 85 mm in height, 85 mm in depth, and 69 mm in width, optimizing space in electrical panels.

Breaking capacity stands at 1 kiloampere, compliant with IEC/EN 61008 standards, delivering robust fault handling capability. The toggle switch actuator enables quick and simple manual resetting of the device post-tripping.

Rated 63A current carrying capacity for industrial and residential circuits. Four pole configuration for comprehensive multi-phase circuit coverage. 30mA trip sensitivity for earth leakage protection. Instantaneous electromagnetic tripping for rapid fault response.

DIN rail mounting format for easy panel integration. 1kA breaking capacity meeting international safety standards. Rated 400V AC operational voltage. Screw terminal connections for secure wiring. Compact dimensions (85mm x 85mm x 69mm) optimize panel space.

Toggle switch actuator for quick reset.

The ABB FH200 series is ideal for a wide range of electrical protection applications in industrial, residential, and commercial installations, offering dependable earth leakage detection and circuit breaker functionality. For reliable residual current protection compliant with IEC/EN standards, the FH200 series by ABB represents an industry-leading solution.
