Eaton Residual Current Circuit Breaker 63A 4-Pole 300 mA Trip Sensitivity Type B 630 A Breaking 167898 FRCDM-63/4/03-G/B

Eaton 167898 FRCDM-63/4/03-G/B Residual Current Circuit Breaker is engineered for high performance protection in electrical systems. It features a 63 ampere current rating with a sensitive 300 mA trip setting designed to detect earth leakage faults rapidly and prevent electrical hazards.

This 4-pole device is suitable for both 220V DC and 240V AC rated applications, making it versatile for various industrial, manufacturing, and commercial use cases. Its electromagnetic tripping mechanism ensures quick disconnection on fault detection to protect equipment and personnel.

The circuit breaker has a compact form factor with dimensions of 80mm in height, 76mm in width, and 70.5mm in depth, allowing easy installation on standard DIN rails. Screw terminals provide robust and reliable wiring connections.

Complying with strict international standards including EN 45545-2, IEC/EN 61008, and IEC 61373, this product ensures high safety, fire protection, and operational reliability. Its breaking capacity of 630A supports safe interruption of high fault currents.

Advanced features include integrated system monitoring with digital preventive warnings before tripping due to leakage currents, reducing downtime and maintenance needs. The device also offers local indication via LEDs and supports photovoltaic applications via configurable pole usage.

This residual current breaker forms part of Eaton's xEffect range, known for providing all-current sensitive residual current devices which detect AC pulsating, DC residual, and smooth DC residual currents. It is ideal for industrial automation, electrical safety installations, and critical infrastructure protection.

Reliable earth leakage protection with Type B tripping characteristic. Rated for 220V DC, 240V AC operation in industrial environments. Electromagnetic tripping mechanism for fast and accurate fault response. Compact DIN rail mountable design with secure screw terminals.

Certified to EN 45545-2, IEC/EN 61008, IEC 61373 standards. System monitoring with digital leakage warnings and LED indicators. High breaking capacity of 630A for fault current handling. Supports photovoltaic and other specialized electrical installations.

Explore the Eaton range at EnvMart for trusted protection devices tailored to industrial and commercial electrical safety requirements.
