Microchip Operational Amplifier 5 MHz, 14-Pin SOIC, 6V MCP6284-E/SL
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 1.5mm |
| Length | 8.65mm |
| Model | MCP6284-E/SL |
| Width | 3.9mm |
| Mount Type | Surface |
| Series | MCP6284 |
| Output Current | 25mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Pin Count | 14 |
| Maximum Supply Voltage | 6V |
| Minimum Supply Voltage | 2.2V |
| GBP - Gain Bandwidth Product | 5MHz |
| Input Bias Current | 1 pA |
| Vos - Input Offset Voltage | ±5 mV |
| Slew Rate | 2.5V/μs |
Key Features
- High gain bandwidth product of 5 MHz suitable for various signal processing applications.
- Surface mount SOIC package with 14 pins facilitates compact circuit designs.
- Operates efficiently with a supply voltage range of 2.2V to 6V.
- Low input bias current of 1 pA ensures high precision signal amplification.
- Wide operating temperature range from -40°C to 125°C for robust industrial use.
- Typical slew rate of 2.5 V/μs enables fast response to input signal changes.
- Four independent amplifier channels integrated into one package.
- Input offset voltage typically ±5 mV ensures accurate amplification performance.
Product Description
Microchip MCP6284-E/SL Operational Amplifier is a high-performance semiconductor device designed for precision analog signal processing. Featuring a 5 MHz gain bandwidth product and housed in a compact 14-pin SOIC surface mount package, this amplifier is ideal for industrial, laboratory, and embedded system applications requiring accurate and stable amplification over a wide operating voltage range of 2.2V to 6V.
The MCP6284 integrates four independent amplifier channels, each with low input bias current of 1 pA and low input offset voltage of ±5 mV, making it suitable for instrumentation and other high-accuracy tasks. Its slew rate of 2.5 V/μs ensures rapid output response, while the maximum output current of 25 mA permits driving moderate load conditions directly.
Designed to operate reliably over a wide temperature range from -40°C to 125°C, this operational amplifier meets the demanding requirements of automotive and industrial environments, although it is not specifically certified as an automotive-grade component. Its compact physical dimensions (8.65 mm length, 3.9 mm width, and 1.5 mm height) enable efficient PCB layout and miniaturization of electronic systems.
High gain bandwidth product of 5 MHz suitable for various signal processing applications. Surface mount SOIC package simplifies automated assembly processes. Wide supply voltage compatibility from 2.2V to 6V ensures design flexibility.
Low input bias current and offset voltage enhance precision and stability. Four channels in a single package reduce component count on PCBs. Fast slew rate offers quick transition times for dynamic signals. Robust operating temperature range supports harsh environments.
Compact size assists in designing space-constrained applications. Output current capability supports a range of load driving needs.
This operational amplifier series from Microchip is suited for diverse applications including industrial controls, test and measurement instruments, communication equipment, and other electronics requiring precise signal conditioning and amplification. The device is supplied new and packaged in tubes for optimized insertion into production lines.
Explore the complete range of Microchip Operational Amplifiers and related semiconductor components at EnvMart for your electronic design projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 5 MHz, making it suitable for various signal processing applications.
It operates efficiently with a supply voltage range from 2.2V to 6V, providing design flexibility for different applications.
This operational amplifier integrates four independent amplifier channels into one package, reducing the component count on PCBs.
The input bias current is 1 pA, which enhances precision in signal amplification.
The typical input offset voltage is ±5 mV, ensuring accurate amplification performance.
It can provide a maximum output current of 25 mA, suitable for driving moderate load conditions directly.
This model operates reliably over a wide temperature range from -40°C to 125°C, making it suitable for robust industrial use.
The MCP6284-E/SL is housed in a compact 14-pin SOIC surface mount package, facilitating efficient PCB layout.
The typical slew rate is 2.5 V/μs, allowing for fast response to input signal changes.
The dimensions are 8.65 mm in length, 3.9 mm in width, and 1.5 mm in height, which supports compact circuit designs.
It is suitable for a variety of applications including industrial controls, test and measurement instruments, and communication equipment that require precise signal conditioning and amplification.
The country of origin for this operational amplifier is India.
