STMicroelectronics Operational Amplifier 1 MHz Gain Bandwidth, 8-Pin SOIC, Surface Mount TL062CDT

STMicroelectronics TL062CDT is a dual channel operational amplifier with a 1 MHz gain bandwidth product and housed in an 8-pin Small Outline Integrated Circuit (SOIC) package designed for surface mounting. It provides low input bias and offset currents with a JFET input stage, making it ideal for precision analog signal amplification and conditioning.

This device operates from a wide supply voltage range of 6 V to 36 V and can function reliably within an ambient temperature range of 0°C to 70°C. It features a low input offset voltage of 20 mV and an input bias current of just 10 nA, ensuring accuracy in sensitive applications. The slew rate of 3.5 V/μs gives it responsive signal amplification capabilities, suitable for audio, sensor interfaces, and general-purpose analog circuits.

Compact and compliant with RoHS environmental standards, the TL062CDT package dimensions are 4.9 mm length, 3.9 mm width, and 1.25 mm height, fitting well in modern compact electronic assemblies. It includes internal frequency compensation and short circuit protection, enhancing robustness in industrial and laboratory environments.

Typical applications include signal amplification in instrumentation, control systems, audio equipment, and various electronic devices requiring low power consumption and low distortion performance. The integrated dual-channel design simplifies circuit complexity for designers.

Dual operational amplifier with JFET inputs and low input bias current. 1 MHz gain bandwidth product suitable for general analog applications. Low input offset voltage and current ensure precision operation. Wide supply voltage range from 6 V to 36 V for compatibility with multiple power systems.

Compact SOIC 8-pin package for efficient surface mounting. Compliant with RoHS environmental regulations. Operating temperature suitable for industrial and consumer environments. Internal frequency compensation and output short circuit protection.

Low power consumption of approximately 200 µA per amplifier. Application versatility in audio, sensor interfacing, control systems, and instrumentation. Explore a wide range of Operational Amplifiers and semiconductor components to suit your electronic design and manufacturing requirements at EnvMart.
