Europa Miniature Circuit Breaker 1-Pole 25A Type C 400V AC 10 kA Breaking Capacity EUC1P
Specifications
| Country of Origin | China |
|---|---|
| Range | EUC1P |
| Brand | Europa |
| Height | 18mm |
| Model | EUC1P |
| Depth | 87mm |
| IP Rating | IP20 |
| Width | 78mm |
| Mount Type | DIN Rail |
| Current Rating | 25A |
| Terminal Capacity | 1mm2 to 25mm2 |
| Series | EUC1P |
| Terminal type | Tunnel |
| Breaking Capacity | 10kA |
| Number of Poles | 1 |
| Standards/Approvals | CE, EN 60898, IEC 60898, SEMKO |
| Rated AC Voltage | 400V ac |
| Tripping Characteristics | Type C |
| Reset Actuator Type | Toggle Switch |
Key Features
- Designed for DIN rail mounting with IP20 protection rating.
- Terminal capacity supports 1mm² to 25mm² wiring.
- Toggle switch actuator for manual reset.
- Complies with IEC 60898 and EN 60898 standards and bears CE and SEMKO approvals.
- Operates efficiently within an ambient temperature range of -5° to 40°C.
- Manufactured in China ensuring quality and reliability.
Product Description
Europa EUC1P Miniature Circuit Breaker, model EUC1P25C, is a single-pole device engineered for electrical protection in residential, commercial, and industrial electrical panels. It features a 25 ampere current rating and Type C tripping characteristics, making it suitable for general-purpose circuit protection where moderate inrush currents occur. It supports 400V AC rated voltage and has a robust breaking capacity of 10 kiloamperes, ensuring safe interruption of short-circuit currents.
The breaker is designed for DIN rail mounting, allowing easy installation in standard consumer units and distribution boards. Its IP20 rating ensures protection against insertion of fingers and foreign objects, enhancing safety during operation. The tunnel terminal type allows secure connections with conductor sizes ranging from 1mm² to 25mm².
Its compact form factor measures 18 mm in height, 78 mm in width, and 87 mm in depth, optimized for efficient use of panel space. The toggle switch actuator facilitates manual reset after tripping events. This device conforms to international standards IEC 60898 and EN 60898 and is certified with CE and SEMKO approvals, affirming its compliance with safety and performance criteria.
Operating reliably in temperatures from -5° to 40°C, this breaker adapts well to typical indoor environments. Originating from China, it provides dependable circuit protection for a wide range of electrical installations.
Designed for DIN rail mounting with IP20 protection rating. Terminal capacity supports 1mm² to 25mm² wiring. Compact dimensions for optimized panel space usage. Toggle switch actuator enables easy manual reset. Meets IEC 60898 and EN 60898 standards with CE, SEMKO approvals.
Operates within ambient temperature -5° to 40°C. Robust breaking capacity of 10 kA for short-circuit protection.
This Europa miniature circuit breaker is ideal for electrical protection in industrial manufacturing, commercial buildings, residential electrical setups, and HVAC control systems. It ensures reliable disconnection and safeguards circuits from overloads and short circuits, enhancing the overall safety and longevity of electrical installations.
Discover the full range of Miniature Circuit Breakers at EnvMart, designed to meet diverse electrical safety requirements with trusted brands like Europa.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Europa Miniature Circuit Breaker has a robust breaking capacity of 10 kiloamperes, ensuring safe interruption of short-circuit currents.
This unit has compact dimensions of 18 mm in height, 78 mm in width, and 87 mm in depth, optimized for efficient use of panel space.
It has a current rating of 25 amperes, suitable for general-purpose circuit protection.
This miniature circuit breaker features Type C tripping characteristics, making it suitable for applications with moderate inrush currents.
The rated AC voltage for this model is 400 volts, making it suitable for various electrical installations.
It supports a terminal capacity of 1 mm² to 25 mm² wiring, allowing for secure electrical connections.
This model is designed for DIN rail mounting, facilitating easy installation in standard consumer units and distribution boards.
It has an IP20 protection rating, ensuring safety against the insertion of fingers and foreign objects during operation.
The breaker operates efficiently within an ambient temperature range of -5° to 40°C, suitable for typical indoor environments.
It complies with IEC 60898 and EN 60898 standards and bears CE and SEMKO approvals, affirming its safety and performance criteria.
This unit features a toggle switch actuator for manual reset after tripping events, allowing for easy operation.
