Renesas Electronics Digital Potentiometer 100-Position 10 kΩ Linear 1-Channel 8-Pin SOIC X9C103SZ
Specifications
| Country of Origin | India |
|---|---|
| Brand | Renesas Electronics |
| Height | 1.5mm |
| Length | 5mm |
| Model | X9C103SZ |
| Width | 4mm |
| Mount Type | Surface |
| Memory type | Non-Volatile |
| Series | X9C10 |
| Temperature Coefficient | 300 ppm/°C |
| Maximum Operating Temperature | 70°C |
| Number of Positions | 100 |
| Resistance | 10kΩ |
| Package Type | SOIC |
| Minimum Operating Temperature | 0°C |
| Interface Type | Serial-3 Wire |
| Pin Count | 8 |
| Minimum Supply Voltage | 5V |
| Taper Type | Linear |
| Number of Pots per Package | 1 |
Key Features
- 100-position digital potentiometer for fine resistance adjustments.
- Linear taper type for predictable resistance variation.
- Single channel device with 10 kΩ resistance.
- Surface mount SOIC package with 8 pins for compact PCB integration.
- Non-volatile memory retains settings without power loss.
- Operates from 5 V supply voltage for standard applications.
- Wide operating temperature range from 0°C to 70°C.
- Serial 3-wire interface enables simple digital control.
Product Description
Renesas Electronics X9C103SZ Digital Potentiometer provides precise resistance control with 100 linear positions and a total resistance of 10 kΩ. The device features a single channel and is housed in an 8-pin SOIC surface-mount package suitable for compact circuit board designs. Designed for use in a variety of electronic applications, it operates at a supply voltage of 5 V and communicates via a serial 3-wire interface for flexible integration with digital control systems.
This digital potentiometer incorporates non-volatile memory, ensuring stored resistance values are retained even when power is removed, making it ideal for adjustable reference and gain control in industrial and consumer electronics. The linear taper ensures resistance changes uniformly with digital inputs, enabling precise analog control through digital signals.
The X9C103SZ maintains performance stability with a temperature coefficient of 300 ppm/°C and can operate reliably within a temperature range of 0°C to 70°C, suitable for most standard environments. Its compact physical dimensions of 5 mm length, 4 mm width, and 1.5 mm height make it suitable for space-constrained designs.
Typical industrial uses include analog signal adjustment, volume controls, programmable gain amplifiers, and trimming circuits in manufacturing, laboratory, and embedded system applications. The device series X9C10 meets the demands for precise digital resistance control with automotive standards excluded.
100-position digital potentiometer for fine resistance adjustments. Linear taper type for predictable resistance variation. Single channel device with 10 kΩ resistance. Surface mount SOIC package with 8 pins for compact PCB integration.
Non-volatile memory retains settings without power loss. Operates from 5 V supply voltage for standard applications. Wide operating temperature range from 0°C to 70°C. Serial 3-wire interface enables simple digital control.
Temperature coefficient of 300 ppm/°C for thermal stability. Compact dimensions (5 mm x 4 mm x 1.5 mm) suitable for dense layouts. Explore more Digital Potentiometers and electronic components in the Electronics Components category on EnvMart to meet your circuit design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The X9C103SZ digital potentiometer has a total resistance value of 10 kΩ.
This model features 100 positions for fine resistance adjustments.
It utilizes a linear taper type for predictable resistance variation.
The digital potentiometer operates from a minimum supply voltage of 5 V.
It can operate reliably within a temperature range of 0°C to 70°C.
It communicates via a serial 3-wire interface, allowing for simple digital control.
The dimensions are 5 mm in length, 4 mm in width, and 1.5 mm in height.
It features non-volatile memory, which retains settings even when power is removed.
The temperature coefficient is 300 ppm/°C, ensuring performance stability.
This model is designed for surface mounting in compact PCB applications.
Typical applications include analog signal adjustment, volume controls, and programmable gain amplifiers.
It is a single-channel device, designed for precise resistance control.
