HOBUT Analogue Panel Ammeter 100 A AC, 72 mm x 72 mm, Class 1.5 Moving Iron D72SD

HOBUT D72SD analogue panel ammeter with a model code D72SD presents a high-accuracy moving iron instrument for measuring AC currents up to 100 A. The device features a compact 72 mm x 72 mm panel dimension ideal for integration into electrical control and process automation systems.

This ammeter is designed with a flame retardant case meeting UL 94V0 requirements, providing safety and durability. The device operates accurately within Class 1.5 specifications and includes a 90-degree scale arc for easy readability.

It supports frequencies between 15 Hz and 400 Hz and withstands operating temperatures from -25°C to +40°C. The ammeter fits panel cutouts of 68 x 68 mm or 92 x 92 mm, and mounting brackets are included to facilitate installation.

Compatible with current transformers having 5 A secondaries, it is optimized for current measurement in industrial process control, electrical automation systems, and monitoring applications where reliable and precise current readings are essential.

Operates on alternating current (AC) with maximum 100 A rating. Moving iron mechanism lends durability and accuracy. Compact panel size of 72 mm x 72 mm enables installation in limited spaces. Class 1.5 accuracy ensures trustworthy measurement results.

Flame retardant case with UL 94V0 rating enhances safety. Wide operating temperature range from -25°C to 40°C. Fits two panel cutout sizes: 68 x 68 mm and 92 x 92 mm. Includes mounting brackets for secure panel fitting. Manufactured according to BS89, CE, DIN 43700, DIN 43802, IEC 51 standards.

Origin: United Kingdom.

This HOBUT D72SD Analogue Panel Ammeter is a reliable choice for electrical and industrial automation control panels, process monitoring and measurement in manufacturing and electrical distribution environments.
