HOBUT Analogue Panel Ammeter 100 A AC, 72 mm x 72 mm, Class 1.5 Moving Iron D72SD

HOBUT D72SD Analogue Panel Ammeter 100 A AC is designed for industrial electrical measurement applications requiring precise current monitoring with high accuracy. This instrument employs a moving iron mechanism and is built to the Class 1.5 accuracy standard, providing reliable and stable readings across a range of AC currents.

The panel meter features a compact 72 mm by 72 mm size suitable for standard panel cutouts measuring 68 x 68 mm or 92 x 92 mm. It accommodates a maximum current rating of 100 A and voltage up to 600 V, making it adaptable for various process control and automation systems.

Constructed with a flame-retardant case compliant with UL94V0, the unit supports operation in temperatures ranging from -25°C to 40°C, ensuring durability in typical industrial environments.

Mounting brackets are supplied for straightforward installation, and the ammeter is compatible with current transformers that provide 5 A secondary currents, expanding its use in systems with CT operation.

Suitable for AC current measurement up to 100 A. Features a moving iron element for accurate current detection. Class 1.5 meter accuracy for reliable operation. Compact panel cutout dimensions of 68 x 68 mm and 92 x 92 mm.

Operational temperature range from -25°C to 40°C. Measures voltage up to 600 V maximum. Flame retardant case complies with UL94V0 standards. Includes mounting brackets for easy installation. Compatible with current transformers with 5 A secondaries.

This ammeter is ideal for industrial automation, electrical panels, process control environments, and other applications requiring dependable analogue current measurement with panel mounting.
