STMicroelectronics Battery Charge Controller IC 2.5V to 12V Input 4.06V Output 1A VFQFPN 16-Pin L6924D013TR
Specifications
| Country of Origin | Philippines |
|---|---|
| Brand | STMicroelectronics |
| Height | 950μm |
| Length | 3.15mm |
| Model | L6924D013TR |
| Mount Type | Surface |
| Series | L6924D |
| Output Current | 1A |
| Maximum Operating Temperature | 125°C |
| Package Type | VFQFPN |
| Sub Type | Battery Charge Controller IC |
| Minimum Operating Temperature | -40°C |
| Pin Count | 16 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 12V |
| Minimum Supply Voltage | 2.5V |
Key Features
- Supports constant current/constant voltage linear charging profiles.
- Operates in quasi-pulse mode to reduce power dissipation with current-limited adapters.
- Integrated power MOSFET, reverse blocking diode, and sense resistor for space efficiency.
- Programmable parameters include pre-charge current, fast-charge current, and charge timer.
- Offers closed-loop thermal control to prevent device overheating.
- Automotive grade with AEC-Q100 standard compliance.
- Wide operating temperature range from -40°C to 125°C.
- Small package size 3.15 mm length and 950 µm height.
Product Description
STMicroelectronics L6924D013TR is a fully monolithic battery charge controller IC designed for efficient charging of single-cell Li-Ion and Lithium Polymer battery packs. It supports input voltage operation from 2.5 V up to 12 V and delivers an output voltage of 4.06 V with a maximum output current of 1 A. This device comes in a compact VFQFPN 16-pin surface mount package measuring 3 x 3 mm, making it ideal for space-constrained applications including handheld equipment and digital cameras.
The L6924D013TR integrates the power MOSFET, reverse blocking diode, and sense resistor to enable simplified battery charging system design. It operates in two modes: a linear constant current/constant voltage (CC/CV) profile when used with a voltage-regulated adapter, and a quasi-pulse mode when combined with a current-limited adapter to reduce power loss and device thermal stress. It features a closed-loop thermal control mechanism to ensure the device remains within safe operating temperatures.
The IC allows users to program key charging parameters such as pre-charge current, fast-charge current, pre-charge voltage threshold, end-of-charge current threshold, and charge timer. It operates reliably under a wide temperature range from -40°C to 125°C and meets the automotive AEC-Q100 standard for enhanced quality and reliability.
Supports constant current/constant voltage linear charging profiles. Quasi-pulse charging mode reduces power dissipation. Fully integrated power components reduce external parts count. Programmable charging parameters for flexible battery management.
Thermal control system prevents overheating during charging. Small form factor VFQFPN 16-pin package for limited space designs. Automotive standard compliance ensures robustness. Wide supply voltage range and operating temperature suitability.
Ideal for handheld devices, digital cameras, and compact battery-powered electronics.
This device belongs to the Battery Management IC segment used widely across industrial, consumer electronic, automotive, and portable equipment applications. For further battery charging solutions and semiconductor components, explore EnvMart's comprehensive catalog of power management integrated circuits from leading manufacturers.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports an input voltage range from 2.5 V to 12 V.
The maximum output current is 1 A.
It has a length of 3.15 mm and a height of 950 μm.
This unit operates within a temperature range of -40°C to 125°C.
It complies with the AEC-Q100 automotive standard.
It supports constant current/constant voltage (CC/CV) linear charging profiles.
This model uses surface mount technology.
It is ideal for handheld devices, digital cameras, and compact battery-powered electronics.
This unit has a pin count of 16.
