Aurora NE-400 Polar Integrating Nephelometer
Specifications
| Ranges | 0.0 to Greater Than 20000 Mm-1 |
|---|---|
| Operating Temperature | - 20 to 45 Degree C |
| Flow Rate | 3 - 9 slpm with internal pump & flow sensor 5 - 17 slpm with External pump & MFC option |
| Dimensions | 260 x 730 x 240 mm |
| Operating Voltage (V) | 12 VDC (incl 110 - 240 VAC 50/60 Hz power supply converter) 120 watts Maximum |
| Light Source | Stable LED light source (US patent 7671988) |
| Lower detectable limit | Less Than 0.1 Mm-1 Full scatter and backscatter(60 second averaged data) |
| Altitude | 2000m (15000m with 24 VDC operation) |
| Calibration | Span gas available for CO2 SF6 FM-200 R-12 R-22 R-134 or a user defined gas |
| Wavelength | 525 nm (green) 450 nm (blue) 635 nm (red) |
| Measured parameters | Light scattering coefficient at (450 525 and 635 nm) over 2 to 18 angular sectors |
| Secondary measurements | Sample temperature Pressure and relative humidity (RH) Multiple Instrument Parameter |
| Operating RH | 10 to 95 % |
| Optics | Reference light source measurement |
| Intensity function | 7 to 173 Degree |
| Weight | 14.2 kg |
| Angular resolution | 1 deg increments within 0.3 deg accuracy |
Key Features
- High powered LED light source increases measurement accuracy
- Single light source and detector used for all wave-lengths
- Heat generated by the LED light source is a fraction of that generated by a flash lamp, minimising changes in sample RH
Product Description
The Acoem Aurora NE-400 Polar is a three-wavelength integrating nephelometer and the flagship of the Aurora NE series.Measure light scattering in up to 18 user-selectable angular sectors, using varied backscatter shutter positioning to help determine the phase function of aerosols and bring our climate research and modeling projects to life with precision data.
- Easy automatic calibration, ensures repeatability of measurement
- Automatic optical reference calibration
- Facilitates a wide measuring range (0 to 20,000 Mm-1)
