Zero Air Generator 8301 Series
Specifications
| Size | 8301 LC and 8301 LC-H height 230 mm (5 RU) with rubber feet width 482 mm depth 352 mm 8301 P height 250 mm width 280 mm (including scrubber canisters) length 565 mm (including optional HCS-1000) |
|---|---|
| Power | 220 VAC 50 Hz (115 VAC 60 Hz optional) |
| Protection Type | Pump is thermally protected |
| Dew Point | -15 Degree C (nominal) (-40 Degree C for low dew point 8301-H) |
| Zero air pressure | 100-200 kPa 200 kPa (nominal for portable version) |
| Air scrubbers | Air clean-up canister for removal of NOx NO NO2 O3 SO2 & H2S Less Less Than 0.1 ppb Optional Air cleanup canister for NH3 or CO2 |
| Zero air flow | 0-10 lpm (std for 8301 LC) 0-20 lpm (std for 8301 LC-H) 0-9 lpm at 200 kPa (std for 8301 P) |
Key Features
- High performance
- High Durability
Product Description
The Acoem (Ecotech) 8301 Series Zero Air Generators have been designed to supply zero air (contaminant free) to a dilution calibration system, such as the Serinus Cal 1000, Serinus Cal 2000, Serinus Cal 3000.The system comprises a compressed air source, permeation dryer, and a series of optional scrubbers chosen depending on the application, producing clean, dry dilution quality zero air.Model 8301LC is designed for a 19 rack-mounted enclosure and provides in excess of 10 slpm of zero airModel 8301LC-H is a high-capacity variant and provides up to 20 slpmModel 8301P provides in excess of 9 slpm of zero air at a pressure of 200 KPa and is ideal for use with dilution gas calibrators
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The 8301LC-H model has a height of 230 mm, a width of 482 mm, and a depth of 352 mm.
The nominal dew point for the 8301 Series is -15 degrees Celsius, with a low dew point option available for the 8301-H model at -40 degrees Celsius.
This unit operates on a power supply of 220 VAC at 50 Hz, with an optional 115 VAC at 60 Hz available.
The air scrubber in this model is an optional clean-up canister that removes contaminants such as NOx, NO, NO2, O3, SO2, and H2S to levels less than 0.1 ppb.
This series is designed to supply zero air to dilution calibration systems, such as the Serinus Cal 1000, Serinus Cal 2000, and Serinus Cal 3000.
The 8301P model has a height of 250 mm.
The pump in this unit is thermally protected.
The 8301LC model provides a standard air flow of 0-10 lpm, while the 8301LC-H model provides a higher capacity air flow of 0-20 lpm.
