Bourns Non-Resettable Fuse 1A 125V AC Ceramic Body Fast Acting SF-2410FP100T-2
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 125V ac |
| Brand | Bourns |
| Body Material | Ceramic |
| Height | 2.6mm |
| Model | SF-2410FP100T-2 |
| Depth | 6.1mm |
| Width | 2.6mm |
| Current Rating | 1A |
| Series | SF-2410FP-T |
| Maximum Operating Temperature | -55°C |
| Resistance | 158mΩ |
| Package Type | Reel |
| Minimum Operating Temperature | 125°C |
| Package Size | 2410 |
| Breaking Capacity | 300A |
| Standards/Approvals | RoHS, UL 248-14 |
| Fuse Characteristics | Fast Acting |
Key Features
- Features a ceramic body for high durability and thermal resistance.
- Designed as a fast acting fuse for precise and rapid current interruption.
- Compact dimensions of 2.6mm width, 2.6mm height, and 6.1mm depth for surface mount applications.
- Breaking capacity of 300A ensures safe circuit protection.
- Halogen-free construction with RoHS and UL 248-14 compliance.
- Package format is a reel of size 2410 suitable for automated assembly.
- Operating temperature ranges from -55°C to a minimum of 125°C.
- Resistance rated at 158 milliohms (mΩ) for minimal power loss.
Product Description
Bourns SF-2410FP100T-2 non-resettable fuse delivers reliable overcurrent protection characterized by a fast acting ceramic tube design. Rated at 1A current and 125V AC voltage, this fuse suits precision fusing speed applications requiring quick circuit interruption.
The fuse measures 2.6mm in width and height, and 6.1mm in depth with a compact 2410 package type allowing surface mount automated assembly. Its robust ceramic body material ensures durability and thermal stability within operating temperatures from -55°C to 125°C.
Engineered with a breaking capacity of 300A, it provides high safety margins for sensitive electronics. Compliance to RoHS standards and UL 248-14 validates its environmental and safety credentials. The product is halogen free, supporting eco-friendly manufacturing requirements.
Typical applications include protection circuits in notebooks, LCD monitors, LCD backlight inverters, power over Ethernet (POE) equipment, POE+ servers, power supplies, game consoles, and white goods. Its resistance of 158 milliohms ensures minimal energy loss to maintain efficiency.
Ceramic body enhances fuse durability and thermal resistance. Fast acting fuse characteristics ensure rapid circuit protection. Compact 2410 package format enables surface mount automated production. Breaking capacity of 300A supports high fault current interrupting.
Complies with RoHS and UL 248-14 safety and environmental standards. Wide operating temperature range from -55°C to 125°C. Low resistance of 158 milliohms reduces power dissipation. Suitability for a broad spectrum of electronic devices and applications.
The fuse is manufactured in Taiwan, Province of China, ensuring consistent quality and industry-standard production. This Bourns model SF-2410FP100T-2 is ideal for industrial, commercial, and consumer electronic applications demanding robust and reliable non-resettable fuse solutions.
Explore more items in the Non Resettable Fuse category for a comprehensive selection of circuit protection components at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Bourns SF-2410FP100T-2 fuse has a current rating of 1A.
This model has a breaking capacity of 300A, providing a high safety margin for circuit protection.
The fuse measures 2.6mm in width, 2.6mm in height, and 6.1mm in depth.
The maximum operating temperature for the Bourns SF-2410FP100T-2 is 125°C.
It is packaged in a reel format of size 2410, suitable for automated assembly.
The fuse features a ceramic body, which enhances its durability and thermal resistance.
The Bourns SF-2410FP100T-2 complies with RoHS and UL 248-14 standards.
The resistance rating of this fuse is 158 milliohms (mΩ), which minimizes power loss.
The minimum operating temperature for the Bourns SF-2410FP100T-2 is -55°C.
This fuse is suitable for applications such as protection circuits in notebooks, LCD monitors, power over Ethernet equipment, and game consoles.
This model is designed as a fast acting fuse, allowing for precise and rapid current interruption.
This fuse is manufactured in Taiwan, Province of China.
