KEMET SPST Through Hole Reed Switch 300 mA 110 V AC/DC Electrical Switch OHD1-30M

Free Delivery in India | Lowest Global Shipping Charges

KEMET SPST Through Hole Reed Switch 300 mA 110 V AC/DC Electrical Switch OHD1-30M

Name: KEMET SPST Through Hole Reed Switch 300 mA 110 V AC/DC Electrical Switch OHD1-30M
Brand: KEMET
SKU: 260167
Price: 655.67 INR
Availability: InStock



Category Reed Switch Brand KEMET Condition New

Specifications

Country of Origin	Japan
Brand	KEMET
Length	18mm
Model	OHD1-30M
Depth	5.6mm
Width	5.5mm
Mount Type	Through Hole
Contact Material	Nickel Iron Alloy
Series	OHD
Maximum Switching Current	300mA
Maximum Operating Temperature	150°C
Contact Configuration	SPST
Minimum Operating Temperature	-20°C
Terminal type	Wire
Contact Resistance	150mΩ
Maximum Switching Power	6W
Standards/Approvals	RoHS
Maximum Switching Voltage	110V ac/dc

Key Features

Single Pole Single Throw (SPST) contact configuration ensures reliable switching performance.
Handles maximum switching current of 300 mA and power up to 6 W.
Designed for through hole mounting with wire terminals for secure connections.
Compact dimensions of 18 mm length, 5.5 mm width, and 5.6 mm depth.
Operational temperature range from -20°C to 150°C allows wide environmental use.
Contact material made of nickel iron alloy ensuring durability and low resistance.
Extremely low contact resistance of 150 milliohms improves electrical efficiency.
RoHS compliant guaranteeing adherence to environmental standards.

Product Description

KEMET OHD1-30M SPST Through Hole Reed Switch is an industrial-grade electrical switch designed for reliable operation in switching electrical signals up to 300 mA and 110 V AC/DC. Featuring a through hole mount and wire terminals, this switch is compact with dimensions of 18 mm length, 5.5 mm width, and 5.6 mm depth, suitable for PCB mounting and embedded circuit applications.

This model utilizes a nickel iron alloy contact material that provides a contact resistance of 150 milliohms, ensuring low power loss during operation. The switch is engineered with a proprietary thermal guard design using Thermorite® - a temperature-sensitive soft ferromagnetic material that decreases magnetic flux density with temperature rise, providing enhanced safety against overheating.

Its wide operating temperature range from -20°C to 150°C supports diverse industrial environments including HVAC systems, motor controls, power modules, amplifiers, and general consumer appliances. Conforming to RoHS standards, the OHD1-30M switch guarantees environmental compliance and robust durability.

The switch demonstrates high-speed response and long operational life with excellent resistance to dust, explosion, and corrosion, making it suitable for harsh industrial and laboratory conditions. Circuit design is simplified due to its compatibility with signals ranging from extremely low (0.1 mW) to high power (6 W) levels.

Single Pole Single Throw (SPST) contact configuration ensures reliable switching performance. Supports maximum switching current of 300 mA and power of 6 W. Through hole mounting with wire terminals provides stable PCB integration.

Compact size facilitates use in space-constrained applications. Wide temperature range from -20°C to 150°C for various environments. Nickel iron alloy contacts with low resistance for efficient operation. RoHS compliant ensuring environmentally safe manufacturing.

Thermal guard technology with Thermorite® enhances thermal protection. Durable against dust, explosion, and corrosion for industrial reliability.

This KEMET Reed Switch is ideal for electrical, HVAC, automotive, manufacturing, and general industrial automation applications. Explore more high-quality switches and electrical components with the KEMET brand on EnvMart.
