Europa Miniature Circuit Breaker 1-Pole, 2A, Type B, 400V AC, 10 kA Breaking Capacity EUC1P

Europa EUC1P Miniature Circuit Breaker, model EUC1P, is a high-quality single-pole circuit protection device designed for industrial and commercial electrical applications. This MCB is rated for 2 amps with Type B tripping characteristics, making it suitable for protecting circuits operating at up to 400V AC. It provides a breaking capacity of 10 kA, ensuring safe interruption of fault currents.

The compact design of this MCB features a height of 18 mm, width of 78 mm, and depth of 87 mm, enabling efficient space utilization in electrical panels. The toggle switch actuator allows for easy manual reset after tripping events. Terminal connections are of tunnel type and support cable sizes ranging from 1 mm² to 25 mm², allowing flexible wiring options.

This device mounts onto a standard 35 mm DIN rail, facilitating quick installation and maintenance. With an IP20 rating, it offers fundamental protection against solid objects, suitable for typical indoor environments. The EUC1P series from Europa conforms to international standards IEC 60898 and EN 60898, and holds approvals from CE and SEMKO, underscoring its safety and reliability credentials.

The breaker operates reliably within an ambient temperature range of -5° to 40° Celsius, making it suitable for various climate conditions in electrical, industrial, and commercial environments. Its robust construction and precise tripping mechanisms offer dependable protection against overloads and short circuits, helping to maintain system stability and safety.

Ideal applications include residential, commercial, and light industrial circuit protection where single-pole switching and reliable current interruption are needed. Provides reliable overcurrent protection with Type B tripping characteristics.

Supports a current rating of 2A for precise circuit protection. Suitable for mounting on 35mm DIN rails with tunnel type terminals. Compact design with dimensions 18mm height, 78mm width, and 87mm depth. Compliant with IEC 60898 and EN 60898 standards for safety and reliability.

IP20 rated enclosure for basic protection against solid objects. Toggle switch reset actuator for convenient operation. Terminal capacity supports wiring from 1mm² to 25mm² cross-section. Manufactured to quality standards and approved by CE and SEMKO.
