Eaton xEffect Miniature Circuit Breaker 2-Pole, 40A, Type D, 415V AC, 10 kA Breaking Capacity 102196 FAZ-D40/2-NA
Specifications
| Country of Origin | India |
|---|---|
| Range | xEffect |
| Brand | Eaton |
| Model | 102196 FAZ-D40/2-NA |
| Depth | 76mm |
| IP Rating | IP20 |
| Width | 105mm |
| Mount Type | DIN Rail |
| Current Rating | 40A |
| Series | xEffect |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 2 |
| Rated AC Voltage | 415V ac |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
Key Features
- The circuit breaker has a current limiting design for short circuit interruption to reduce circuit damage.
- Rated for currents up to 63A ensuring versatile application.
- Toggle switch can be sealed in on and off positions providing secure operation.
- Thermal magnetic tripping mechanism offers six levels of over-current protection.
- Red or green indicator light shows contact position clearly.
- Easy to install with DIN Rail mounting and screw terminal type.
- Suitable for supplementary protection in industrial and commercial applications.
- Compact size with 105mm width and 76mm depth for space saving.
Product Description
Eaton 102196 FAZ-D40/2-NA Miniature Circuit Breaker is a high-quality, thermal magnetic trip device designed for industrial and commercial electrical protection. This 2-pole circuit breaker supports a current rating of 40A and an AC voltage of 415V. It provides a breaking capacity of 10 kA making it reliable for harsh electrical environments.
The FAZ series from Eaton is known for its robust construction and short circuit energy limitation, reducing let-through energy that could damage electrical circuits. The toggle switch features a trip-free design preventing manual override to enhance safety in installations. Visual indication of the contact position is provided by red and green lights.
This Miniature Circuit Breaker mounts easily on DIN rails and uses screw terminals for secure wiring connections. With an IP20 rating, the breaker offers protection against accidental contact. Its dimensions (105mm width and 76mm depth) make it suitable for compact control panels and electrical enclosures.
Applications include use in industrial machinery, HVAC systems, water treatment plants, manufacturing lines, and commercial electrical installations. The device complies with necessary functional standards though no specific approvals are listed, ensuring safe and reliable operation.
The circuit breaker has a current limiting design for short circuit interruption to reduce circuit damage. Rated for currents up to 63A ensuring versatile application. Toggle switch can be sealed in on and off positions providing secure operation.
Thermal magnetic tripping mechanism offers six levels of over-current protection. Red or green indicator light shows contact position clearly. Easy to install with DIN Rail mounting and screw terminal type. Suitable for supplementary protection in industrial and commercial applications.
Compact size with 105mm width and 76mm depth for space saving. Explore the Electronics & Electricals section on EnvMart to find more high-quality circuit breakers and electrical protection devices from Eaton and other leading brands.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 40A, suitable for various applications.
The breaking capacity of this circuit breaker is 10 kA, making it reliable for harsh electrical environments.
It is rated for an AC voltage of 415V, suitable for industrial and commercial applications.
It features a thermal magnetic tripping mechanism that offers six levels of over-current protection.
This unit is designed for DIN Rail mounting, allowing for easy installation in control panels.
The dimensions are 105mm in width and 76mm in depth, making it compact for space-saving installations.
It uses screw terminals for secure wiring connections, enhancing reliability in installations.
The breaker has an IP20 rating, providing protection against accidental contact.
The toggle switch can be sealed in on and off positions, providing secure operation and preventing manual override.
It is suitable for supplementary protection in industrial machinery, HVAC systems, and commercial electrical installations.
This model is part of the xEffect series from Eaton, known for its current limiting design.
The tripping characteristics are classified as Type D, suitable for applications requiring high inrush current tolerance.
