Eaton xEffect Miniature Circuit Breaker, 2-Pole, 16A, Type D, 415V ac, 10 kA Breaking Capacity 102190 FAZ-D16/2-NA
Specifications
| Country of Origin | India |
|---|---|
| Range | xEffect |
| Brand | Eaton |
| Model | 102190 FAZ-D16/2-NA |
| Depth | 76mm |
| IP Rating | IP20 |
| Width | 105mm |
| Mount Type | DIN Rail |
| Current Rating | 16A |
| Series | xEffect |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 2 |
| Rated AC Voltage | 415V ac |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
| Cooper Bussmann 6.25A T Melamine Cartridge Fuse, 10 x 38mmBrand | Cooper Bussmann |
Key Features
- Designed for 415V AC voltage systems with 10 kA breaking capacity.
- Features thermal magnetic tripping mechanism for reliable overcurrent protection.
- DIN rail mountable with screw terminal type ensuring easy installation.
- Includes toggle switch reset actuator with trip-free design to prevent override.
- Compact dimensions with width 105mm and depth 76mm, IP20 rated for indoor protection.
- Red or green indicator light displays contact position, ensuring operational status clarity.
- Provides six levels of thermal-magnetic protection for safe circuit interrupting.
- Suitable for supplementary protection in industrial or commercial electrical installations.
Product Description
Eaton 102190 FAZ-D16/2-NA Miniature Circuit Breaker is engineered for secure operation in electrical distribution and control panel systems. This 2-pole circuit breaker supports a current rating of 16A with Type D tripping characteristics, optimized for handling moderate inrush currents without nuisance tripping.
Operating at a rated AC voltage of 415V, it offers a breaking capacity of 10 kA, providing robust short circuit interruption to minimize damage to electrical circuits. Its thermal magnetic trip mechanism ensures dependable response to overcurrent conditions by combining thermal elements for overload protection and magnetic elements for instantaneous short circuit interruption.
With a DIN rail mounting format and screw terminal connections, installation is straightforward and secure. The toggle switch reset actuator comes with a trip-free design, ensuring the breaker cannot be bypassed by holding the handle in the ON position. Furthermore, it features visual contact position indication through red or green lights.
This circuit breaker, part of the Eaton xEffect series, is compact with a width of 105mm and depth of 76mm, rated for indoor applications with an IP20 ingress protection rating. It is suitable for supplementary protection, making it ideal for industrial, commercial, and residential electrical safety applications.
Operates up to 63A rated currents within the series. Current limiting design reduces let-through energy during short circuits. Toggle switch can be sealed in ON or OFF position for additional safety. Manufactured to provide reliable and safe circuit interruption.
Ideal for use in electrical distribution panels and control systems.
Choose this reliable Eaton Miniature Circuit Breaker for enhanced protection and ease of installation in varied environments. Explore similar circuit breakers and electrical protection devices in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 16A.
It offers a breaking capacity of 10 kA, providing robust short circuit interruption.
The circuit breaker is designed for a rated AC voltage of 415V.
It is designed for DIN rail mounting, ensuring straightforward and secure installation.
It features a thermal magnetic tripping mechanism for reliable overcurrent protection.
This unit has a width of 105mm and a depth of 76mm.
It is rated IP20, making it suitable for indoor applications.
It includes a toggle switch reset actuator with a trip-free design to prevent override.
It is suitable for supplementary protection in industrial, commercial, and residential electrical installations.
This model has Type D tripping characteristics, optimized for handling moderate inrush currents without nuisance tripping.
Yes, the toggle switch can be sealed in the ON or OFF position for additional safety.
The country of origin is India.
