Burkert Angle Type Pneumatic Actuated Valve Stainless Steel 16 bar 1.5 in 178864
Specifications
| Country of Origin | Germany |
|---|---|
| Brand | Burkert |
| Maximum Operating Pressure | 16 bar |
| Inlet Connection Type | Threaded |
| Model | 178864 |
| Valve Type | Angle |
| Ambient temperature range | - 10 to +60°C |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -10°C |
| Valve Material | Stainless Steel |
| Inlet Port Size | 1.5 in |
| Outlet Thread Standard | G |
| Return Type | Spring |
| Media temperature range | - 10 to +180°C |
Key Features
- The valve features a stainless steel angle seat for durability.
- It supports a maximum operating pressure of 16 bar.
- Inlet and outlet connections are threaded with a port size of 1.5 inches.
- Operates with a normally open (NO) valve position by spring return.
- Ambient temperature range from -10°C to +60°C for versatile environmental conditions.
- Suitable for use with neutral gases, air, steam, water, and oil.
- Compact design allows for high flow rates.
- Equipped with a polyamide actuator casing and PTFE seals for reliability.
Product Description
Burkert 178864 pneumatic actuated valve is a robust angle seat valve built with stainless steel material capable of handling maximum pressure of 16 bar. It features threaded inlet and outlet connections sized at 1.5 inches, designed to facilitate reliable fluid control in industrial environments.
The valve operates normally open with a spring return mechanism ensuring default valve position. It utilizes a polyamide actuator casing combined with PTFE seal materials to provide long-lasting durability and chemical resistance.
This valve is suitable for controlling neutral gases, air, steam, water, and oil, catering to multiple industrial applications including manufacturing, chemical processing, HVAC systems, and water treatment.
Designed for stable operation within ambient temperatures ranging from -10°C to +60°C and media temperatures from -10°C up to +180°C, this valve supports demanding industrial conditions with consistent performance.
The stainless steel valve material ensures high corrosion resistance and mechanical strength. Self-adjusting spindle packing glands and wiper seals reduce maintenance needs. High flow rates are achievable due to the compact and optimized angle seat design.
The valve's spring return provides reliable default closed or open position as required. Threaded inlet and outlet ports allow for easy installation and replacement.
Valve with flow direction above the seat is primarily suited for gases and steam but is conditionally usable with liquids due to potential water hammer effects. The product is manufactured in Germany ensuring quality and compliance with industry standards.
Set includes one pneumatic actuated angle seat valve. This product is ideal for professionals seeking a durable and efficient valve solution for pneumatic applications. Browse the Industrial Valves & Valve Fittings category at EnvMart for more Pneumatic Actuated Valve options from Burkert and other leading brands.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating pressure of this valve is 16 bar.
The inlet port size of this valve is 1.5 inches.
The valve is constructed from stainless steel, with a polyamide actuator casing and PTFE seals.
The ambient temperature range for this valve is from -10°C to +60°C.
This valve is suitable for controlling neutral gases, air, steam, water, and oil.
It operates with a normally open (NO) position by spring return, ensuring a default valve position.
The maximum media temperature that this valve can handle is 180°C.
The valve features threaded inlet and outlet connections.
This valve is manufactured in Germany.
The valve type is an angle valve.
The compact and optimized angle seat design allows for high flow rates.
The return type of this valve is spring-operated.
