Infineon 8-bit PSoC M8C Microcontroller, 24 MHz, 4kB FLASH, 8-Pin SOIC CY8C24123A-24SXI

Infineon CY8C24123A-24SXI is an 8-bit PSoC microcontroller featuring the M8C Harvard-architecture core with a maximum clock frequency of 24 MHz and 4kB of FLASH program memory packaged in an 8-pin SOIC form factor. It is designed for efficient embedded applications requiring low power consumption and high flexibility.

This microcontroller operates over a voltage range from 3.0 V to 5.25 V and supports an automotive temperature range from minus 40°C to plus 85°C, making it ideal for harsh industrial and automotive environments.

Equipped with advanced peripherals, it includes a 9-bit DAC, a 14-bit ADC, two analogue comparators, and multiple digital PSoC blocks such as timers, counters, and PWM modules. Communication interfaces include UART, SPI, and API, allowing flexible integration into various systems.

The CY8C24123A-24SXI microcontroller also features in-system serial programming, partial flash updates, and flexible protection modes including EEPROM emulation in flash memory. The seven configurable GPIO pins provide pull-up, pull-down, high impedance, strong, or open-drain drive modes, with programmable pin interrupts.

Development is supported through free PSoC Designer software and a full-featured in-circuit emulator and programmer, enabling rapid prototyping and debugging for industrial, automotive, consumer electronics, and embedded computing applications.

Features a powerful Harvard-architecture processor for efficient performance. Operating voltage range from 3.0 V to 5.25 V ensuring low power consumption at high speeds. Includes advanced peripherals such as DAC and ADC with 9-bit and 14-bit resolution respectively.

Supports multiple interfaces including API, SPI, and UART for versatile connectivity. Designed for automotive temperature range from -40°C to +85°C for reliable operation. Offers 6 programmable I/O pins with flexible pin configurations.

Includes 2 timers, 2 analogue comparators, and integrated watchdog and sleep timers. Compatible with free development software and full-featured in-circuit emulator tools.

This microcontroller finds applications in industrial control systems, automotive electronics, sensor monitoring, digital signal processing, and low-power embedded designs. Its flexible analog and digital peripherals facilitate complex embedded functions while minimizing external components.
