Hongfa Europe GMBH PCB Power Relay 5V dc Coil 10A Switching Current DPDT HF140FF/005-2ZSTF
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 26.3mm |
| Length | 29mm |
| Model | HF140FF/005-2ZSTF |
| Width | 13mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HF140FF |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Contact Resistance | 50mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 47Ω |
| Coil Voltage | 5V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 250V |
| Coil Power | 530mW |
Key Features
- High power switching up to 240W for DC applications.
- Operational temperature range from -40°C to 85°C.
- 5KVAC isolation voltage between coil and contacts.
- Silver alloy contact material offers durability and reliability.
- Plastic sealed type ensures environmental resistance.
- Designed for PCB mounting with PCB pin terminals.
- Durable for up to 10 million mechanical cycles.
- Suitable for automotive and industrial control device applications.
Product Description
Hongfa Europe GMBH HF140FF/005-2ZSTF is a DPDT non-latching PCB Power Relay designed for intermediate power switching with a 5V direct current coil and capable of handling up to 10 amps of switching current.
This relay features silver alloy contacts and is housed in a plastic sealed enclosure, making it environmentally friendly and robust for long-term usage. The reliable coil resistance of 47 ohms and coil power of 530 mW ensure stable actuation performance.
It supports a switching power of up to 2.5 kVA, with switching DC voltage rated at 30V dc and AC voltage at 250V AC, suitable for various electronic and automotive control systems.
The relay is designed for PCB mounting and employs PCB pin terminals facilitating easy installation in printed circuit boards. It operates efficiently in temperatures ranging from -40°C to 85°C, with an isolation voltage of 5 KVAC between coil and contact to ensure user safety and device protection.
This model is ideal for applications in industrial automation, automotive electronics, and control devices requiring reliable switching capabilities. Its high durability, supporting up to 10 million mechanical cycles, ensures longevity in demanding environments.
High power switching capacity of 240W DC. Wide temperature operating range from -40°C to 85°C. 5KVAC isolation voltage for enhanced safety. Silver alloy contacts for robust performance. Plastic sealed relay for environmental protection.
PCB mount with pin terminals for easy integration. Durable up to 10 million cycles. Applicable for automotive and industrial control devices.
Choose this Hongfa Europe GMBH PCB power relay for reliable, high performance, and long-lasting switching solutions in your electronic designs. Explore more Power Relays and related products at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model can handle a maximum switching current of 10A.
It requires a coil voltage of 5V DC for operation.
The isolation voltage between the coil and contacts is 5KVAC.
The operational temperature range is from -40°C to 85°C.
The dimensions are 29mm in length, 13mm in width, and 26.3mm in height.
It features a DPDT (Double Pole Double Throw) contact configuration.
The contacts are made from silver alloy, which provides durability and reliability.
This model is designed to support up to 10 million mechanical cycles.
It has a high power switching capacity of 240W for DC applications.
The contact resistance is rated at 50mΩ.
It is designed for PCB mounting and uses PCB pin terminals for installation.
Yes, it complies with RoHS standards.
