Alpha Wire Cable Gland M25 Thread Size, Grey Chloroprene Rubber & Polyamide, Clamping 11-17 mm, IP66 IP68 PMC25 SL080

Alpha Wire PMC25 SL080 cable gland is a premium quality wire management solution designed for robust strain relief and sealing in electrical installations. This cable gland features a polyamide 6 body combined with a chloroprene rubber O-ring seal, offering excellent resistance to environmental elements and mechanical stress.

Engineered with an M25 x 1.5 metric thread size, it accommodates cable diameters ranging from 11 mm minimum to 17 mm maximum, fitting securely with a thread length of 8 mm and diameter of 25 mm. The grey color blends with typical industrial cabling infrastructure.

Designed for challenging industrial and commercial environments, the gland provides ingress protection ratings IP66 and IP68, ensuring it is dust-tight and capable of withstanding submersion under fresh water up to 5 bar pressure for 30 minutes. It resists temperature extremes from -20°C (minimum operating temperature) to an intermittent maximum of 150°C, suitable for demanding HVAC, manufacturing, telecommunications, and electrical power usage.

The gland’s compliance with CSA C22.2, UL 514, and UL 94V-2 flammability standard signifies safety in use, with a V2 rating indicating flame retardance according to UL94 standards. Supplied with a locknut, it provides secure clamping and effective strain relief to protect wires and cables from damage caused by tension or vibration.

Constructed with a polyamide 6 body and chloroprene rubber O-ring to ensure durability and sealing integrity. Suitable for cable diameters between 11 mm and 17 mm providing versatility in application. Temperature endurance from -20°C to +150°C (intermittent), ensuring performance in varied conditions.

Achieves IP66 and IP68 ingress protection ratings for resistance against dust and water ingress. Conforms to safety and flammability standards including CSA C22.2, UL 514, and UL 94V-2 (V2 rating). Includes locknut for secure installation and reliable strain relief.

Ideal for use in telecommunications, instrumentation, control systems and electrical power applications.

This Cable Gland supports industrial, commercial, and manufacturing environments requiring robust cable management solutions. Its high-quality construction protects cable systems from wear, water, dust, and thermal stress, extending service life and maintaining system safety.

Explore additional components and compatible accessories within the Alpha Wire FIT Wire Management series for comprehensive wiring protection and infrastructure management solutions.
