TE Connectivity Slide Rotary Coded DIP Switch Through Hole Mount 50mΩ Contact Resistance 1825057-6

TE Connectivity model 1825057-6 is a Slide Rotary Coded DIP Switch designed with a through hole mount providing ease of assembly on PCBs. It features a slide type actuator that offers reliable and precise switching action with low contact resistance of 50mΩ, optimizing signal performance in electronic circuits.

This DIP switch has gold flash plated contacts seated in a robust black PPS housing to ensure durability and longevity. The contacts incorporate a high pressure wiping contact system which allows for aqueous or solvent cleaning without the need for tape seals. This makes the switch suitable for demanding manufacturing environments.

The compact switch dimensions are 7.5 x 3.5 mm with a standard 2.54 mm centerline pitch, making it compatible with standard PCB layouts. It is compatible with vapor phase reflow and wave soldering processes used in automated assembly lines, enhancing production efficiency.

These properties make it ideal for use in a variety of industrial, electrical, and automation systems requiring precise rotary coded switching functionality. Mount type is through hole, enabling secure PCB mounting. Slide actuator type offers smooth operational control.

Gold flash plated contacts resist corrosion and ensure conductivity. High pressure wiping contacts allow robust cleaning and lasting reliability. Compact form factor suits miniature electronic designs. Contact resistance of 50 milliohms supports clear signal transmission.

Manufactured in China adhering to TE Connectivity’s quality standards. Explore the TE Connectivity products and enhance application reliability with exact fits and robust specifications across electronics and automation sectors.
