ZF Roller Lever Micro Switch, Left Angle PCB Terminal, SPDT, 3A, 125 V ac, IP40 DG13-B3RA

Free Delivery in India | Lowest Global Shipping Charges

ZF Roller Lever Micro Switch, Left Angle PCB Terminal, SPDT, 3A, 125 V ac, IP40 DG13-B3RA



Category Micro Switches Brand ZF Condition New

Specifications

Country of Origin	India
Brand	ZF
Operating Temperature Range	-25 to +85°C
Model	DG13-B3RA
IP Rating	IP40
Housing Material	Polyphenylene Sulphide
Series	DG Sub-Miniature
Maximum Operating Temperature	85°C
Contact Configuration	SPDT
Actuator Type	Roller Lever
Minimum Operating Temperature	-25°C
Terminal type	Left Angle PCB Terminal
Standards/Approvals	RoHS
Switch Contact Current	3A
Operating Force	0.59N
Mechanical Life	1000000Operations
Contact AC Voltage	125V ac
Microswitch Type	DG Subminiature

Key Features

Features a durable roller lever actuator for precision operation.
Equipped with left angle PCB terminals for efficient circuit board mounting.
Silver-plated SPDT contacts ensure reliable electrical performance.
Constructed with polyphenylene sulphide housing for high durability and UL94V-0 flame resistance.
Operates reliably within a temperature range of -25°C to 85°C.
Offers a mechanical life expectancy of 1,000,000 operations for enduring use.
IP40 rated housing provides basic protection against solid objects.
RoHS compliant, meeting environmental and safety standards.

Product Description

ZF DG13-B3RA roller lever micro switch features a left angle PCB terminal design, enabling easy mounting on circuit boards. Designed with a robust roller lever actuator, this SPDT switch supports a switching contact current of 3A at 125 V ac and ensures reliable operation in industrial and electronic applications.

The switch housing is molded from polyphenylene sulphide material compliant with UL94V-0 flammability standards, providing flame retardant protection. The device operates within a broad temperature range from -25°C to 85°C, making it suitable for diverse industrial environments.

Equipped with silver-plated wiping contacts, the switch promises excellent electrical conductivity and durability. With a mechanical life rating of one million operations, it guarantees long-lasting performance under repeated actuation.

Its IP40 rating offers protection against solid objects greater than 1 mm, suitable for general indoor use. The switch meets RoHS directives and holds UL recognition along with CSA certification, assuring compliance with safety and environmental standards.

This micro switch is ideal for use in industrial automation, control panels, electrical devices, and electronic equipment where precise switching is required. Package contains one unit of ZF DG13-B3RA micro switch ready for PCB assembly.

Features a durable roller lever actuator for precision operation. Equipped with left angle PCB terminals for efficient circuit board mounting. Silver-plated SPDT contacts ensure reliable electrical performance. Constructed with polyphenylene sulphide housing for high durability and UL94V-0 flame resistance.

Operates reliably within a temperature range of -25°C to 85°C. Offers a mechanical life expectancy of 1,000,000 operations for enduring use. IP40 rated housing provides basic protection against solid objects. RoHS compliant, meeting environmental and safety standards.

UL recognized component and CSA certified for safety assurance. Explore more Micro Switches and electrical components suitable for industrial automation and control systems at EnvMart.
