Isocom DC Input Optocoupler Through Hole 2-Pin DIP TLP621GB

Isocom TLP621GB DC Input Optocoupler is designed to provide electrical isolation between input and output, incorporating an infrared light-emitting diode and an NPN silicon phototransistor in a compact 2-pin DIP through-hole package. This optocoupler enables safe and reliable signal transmission across circuits operating at different potentials and impedances.

The device features a maximum forward voltage of 1.3 V and an input current type of DC, making it suitable for a variety of low voltage applications. It supports a maximum input current of 50 mA and maintains a high isolation voltage rating of 5300 Vrms for effective protection against high voltage spikes.

The TLP621GB operates efficiently within a temperature range from -30°C to 100°C, ensuring stable performance in harsh environments common to industrial automation, computer terminals, and measuring instruments.

With a minimum current transfer ratio of 100%, the optocoupler guarantees consistent switching response, while its typical rise and fall times of 2 μs and 3 μs respectively allow for fast signal processing. The package type is DIP, facilitating easy installation in through-hole PCB layouts.

This product meets UL certification standards, underscoring its reliability and safety compliance. Packaged in tubes containing single-channel optocouplers, it is ideal for use in industrial system controllers, signal transmission between different circuit potentials, and electronic instrumentation.

Features an infrared LED and NPN photo transistor in a space-efficient DIP package. Provides AC isolation voltage of 5300 Vrms for electrical safety. Wide operating temperature range of -30°C to 100°C suits varied applications.

Minimum current transfer ratio rated at 100% ensures consistent signal transfer. Typical rise and fall times of 2μs and 3μs support rapid switching. UL certified for dependable performance and safety. Tube packaging simplifies storage and handling.

Manufactured in Thailand adhering to quality standards.

Isocom TLP621GB is widely applicable in industrial, computing, measurement, and controller systems requiring robust electrical isolation and rapid signal transmission. For more electronic components, explore the Optocoupler category at EnvMart to find compatible products tailored to your technical requirements.
