Preci-Dip 811 Series Straight Through Hole Spring Loaded Connector 11 Contacts 2.54 mm Pitch 1 Row 811-S1-011-10-017101

Preci-Dip 811 Series Spring Loaded Connector model 811-S1-011-10-017101 is a precision electronic component tailored for PCB connectivity requiring secure mechanical and electrical performance. It features 11 spring-loaded contacts arranged in a single straight row with a 2.54 mm pitch, making it ideal for compact electronic device assembly.

The connector's housing is manufactured from fibreglass reinforced polyethylene terephthalate material, providing excellent mechanical strength and thermal stability. The gold-plated brass contacts deliver a low resistance path with high corrosion resistance, ensuring consistent signal quality.

Designed for through-hole PCB mounting, this connector provides a robust mechanical connection fitted for industrial, laboratory, manufacturing, and electronics production environments. Operating within -55°C to 125°C temperature limits, it can withstand demanding thermal conditions often encountered in industrial applications.

The 1.4 mm plunger stroke length combined with spring-loaded contacts guarantees reliable multipoint electrical connectivity even under vibration or mechanical movement. The shrouded design protects the contacts and reduces the risk of accidental shorts during assembly or operation.

Utilizes spring-loaded contacts for stable and low resistance connections. Rated for 3.5 amps current, suitable for moderate power circuits. Housing constructed from durable fibreglass reinforced polyethylene terephthalate.

Gold plating on brass contacts enhances conductivity and corrosion resistance. Shrouded straight single row design prevents damage and accidental shorts. Through-hole mounting ensures a stable and secure PCB attachment. Wide operating temperature range from -55°C to 125°C for extreme environments.

Manufactured in Switzerland, verifies high-quality standards.

These connectors are widely used across industrial automation, electronics manufacturing, telecommunications, and lab equipment where reliable and compact PCB connections are critical. They offer a premium alternative to traditional connectors by minimizing micro-discontinuities and contact resistance over time.
