Preci-Dip 811 Series Straight Through Hole Spring Loaded Connector, 5 Contacts, 2.54 mm Pitch, 1 Row 811-S1-005-10-017101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 811 Series Straight Through Hole Spring Loaded Connector, 5 Contacts, 2.54 mm Pitch, 1 Row 811-S1-005-10-017101

Name: Preci-Dip 811 Series Straight Through Hole Spring Loaded Connector, 5 Contacts, 2.54 mm Pitch, 1 Row 811-S1-005-10-017101
Brand: Preci-Dip
SKU: 215282
Price: 5.64 USD
Availability: InStock



Category Spring Loaded Connector Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	150V
Brand	Preci-Dip
Orientation	Straight
Current	3.5A
Model	811-S1-005-10-017101
Mount Type	Through Hole
Housing Material	Fibreglass Reinforced Polyethylene Terephthalate
Contact Material	Brass
Series	811
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	5
Contact Gender	Male
Shrouded/Unshrouded	Shrouded

Key Features

Offers 3.5A current rating with reliable electrical performance.
Constructed with brass contacts plated with gold for corrosion resistance.
Fibreglass reinforced polyethylene terephthalate housing ensures durability.
Operates within a temperature range of -55°C to 125°C.
Designed with straight orientation and solder termination type for secure PCB connection.
Compact, single-row design facilitates efficient PCB layout and assembly.
Manufactured in Switzerland to high quality standards.

Product Description

Preci-Dip 811-S1-005-10-017101 is a high-quality straight through hole Spring Loaded Connector designed for electronic assemblies requiring stable and low-resistance connections. It features 5 spring-loaded contacts arranged in a single row with a pitch of 2.54 mm. The contacts are crafted from brass and plated with gold to ensure reliable conductivity and resistance to corrosion.

The housing is made from fibreglass reinforced polyethylene terephthalate, providing robust mechanical strength and shrouded protection to safeguard the contacts. The connector is optimized for through hole mounting on PCBs and offers solder termination type for secure and durable electrical connections.

Electrical specifications include a current rating of 3.5 A and operating voltage up to 150 V. The connector is designed to operate reliably in harsh environments with a wide temperature tolerance from -55°C to 125°C.

This connector is an excellent choice for industrial, laboratory, electronic manufacturing, and automation applications where stable multipoint connections with spring-loaded contacts are required. The low electrical resistance compensates for vibration and movement, ensuring consistent signal integrity.

Current rating of 3.5 A suitable for moderate power signals. Gold-plated brass contacts for durability and performance. Fibreglass reinforced housing provides mechanical stability. Wide operating temperature range supports various environments.

Straight orientation and solder termination for ease of assembly. Compact single-row design with 2.54 mm pitch for PCB integration.

Preci-Dip connectors set the standard for reliability in spring-loaded contact technology, widely used in electronic components, power connectors, and PCB assembly industries. This model is manufactured in Switzerland, assuring premium build quality and adherence to international standards.

Explore more electronic connectors and components at EnvMart to meet your project requirements with high-quality brands like Preci-Dip.
