Preci-Dip 4 Way Right Angle Through Hole 2.54 mm Pitch SIL Socket 100 V ac, 150 V dc, Solder, 3A 399-87-104-10-003101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 4 Way Right Angle Through Hole 2.54 mm Pitch SIL Socket 100 V ac, 150 V dc, Solder, 3A 399-87-104-10-003101

Name: Preci-Dip 4 Way Right Angle Through Hole 2.54 mm Pitch SIL Socket 100 V ac, 150 V dc, Solder, 3A 399-87-104-10-003101
Brand: Preci-Dip
SKU: 215190
Price: 0.67 USD
Availability: InStock



Category SIL Sockets Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	100, 150V ac
Brand	Preci-Dip
Orientation	Right Angle
Current	3A
Length	10.16mm
Depth	2.54mm
Width	2.95mm
Mount Type	Through Hole
Housing Material	Fibreglass Reinforced Polycyclohexylenedimethylene Terephthalate
Contact Material	Beryllium Copper Alloy, Brass
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Pitch	2.54mm
Contact Plating	Tin, Gold
Number of Contacts	4

Key Features

The socket features a 2.54 mm pitch suitable for precise electronic assemblies.
Constructed with beryllium copper alloy and brass contacts for durability and conductivity.
Contacts are plated with tin and gold to ensure reliable connections.
Right angle orientation and through hole mount type provide secure PCB integration.
The housing is made from fibreglass reinforced polycyclohexylenedimethylene terephthalate for robust insulation.
Rated for operation from -55°C up to 125°C, suitable for various environmental conditions.
Termination type is solder, enabling dependable secure connections in assemblies.
Compact dimensions of length 10.16 mm, width 2.95 mm, and depth 2.54 mm allow for space-efficient design.

Product Description

Preci-Dip 399-87-104-10-003101 4 Way Right Angle Through Hole 2.54 mm Pitch SIL Socket is designed for applications requiring reliable electronic connections under 100 V ac and 150 V dc with a current rating of 3A. The device is ideal for industrial, laboratory, and manufacturing electronics assemblies where precision and durability are critical.

This SIL socket features contact materials of beryllium copper alloy combined with brass, providing excellent conductivity and mechanical strength. The contacts have tin plating with a flash of gold to enhance signal quality and corrosion resistance. The right angle orientation and through hole mounting allow stable PCB installation, beneficial for designing compact and robust circuits.

The housing is fabricated from fibreglass reinforced polycyclohexylenedimethylene terephthalate, offering high insulation properties and mechanical endurance. The socket operates reliably within a temperature range from -55°C to 125°C, making it suitable for diverse operating environments, including harsh industrial applications.

Key dimensions of the socket include a length of 10.16 mm, width of 2.95 mm, and depth of 2.54 mm, allowing tight integration with other components. The termination uses solder technology, ensuring strong and durable electrical connections.

This product is manufactured in Switzerland, assuring high quality standards and precision engineering. The socket features a 2.54 mm pitch for precise pin alignment. Contact material alloy ensures durability and conductivity.

Gold flash plating enhances connection reliability. Right angle and through hole mounting secure PCB assembly. Wide operating temperature range from -55°C to 125°C. Compact size suits space-constrained electronic designs.

Manufactured in Switzerland ensuring top quality.

Suitable for electronics manufacturing, industrial control systems, telecommunications, and instrumentation applications. This SIL socket is an essential component for reliable, high-performance electronics assembly. Explore related SIL Sockets and electronic components in the Electronics & Electricals category on EnvMart.
