SMC Pneumatic Guided Cylinder 12mm Bore, MXS Series Double Acting, 75 mm Stroke MXS12-75

Free Delivery in India | Lowest Global Shipping Charges

SMC Pneumatic Guided Cylinder 12mm Bore, MXS Series Double Acting, 75 mm Stroke MXS12-75



Category Pneumatic Guided Cylinder Brand SMC Condition New

Specifications

Country of Origin	India
Brand	SMC
Body Material	Aluminium Alloy
Maximum Operating Pressure	0.7 Mpa
Height	32mm
Length	158mm
Model	MXS12-75
Gross Weight	660g
Width	50mm
Mount Type	Through Hole
Series	MXS
Maximum Operating Temperature	60°C
Minimum Operating Temperature	-10°C
Stroke Length	75mm
Bore Diameter	12mm
Action Type	Double Acting
Cushioning Type	Rubber
Guide Type	Slide Bearing
Piston Rod Thread Size	M5

Key Features

Constructed with durable aluminium alloy body for lightweight and corrosion resistance.
Features rubber cushioning for smooth operation and noise reduction.
Operating temperature range from -10°C to 60°C suitable for varied environments.
Slide bearing guide type for accurate and stable motion.
Designed for a maximum operating pressure of 0.7 Mpa.
Equipped with M5 piston rod thread size for secure attachments.
Maximum piston speed up to 500 mm/s enabling fast actuation.
Double acting air cylinder with through hole mount type for versatile installation.

Product Description

SMC MXS12-75 Pneumatic Guided Cylinder is engineered for precise, double acting linear motion in industrial automation and fluid power applications. With a 12mm bore and 75mm stroke length, this cylinder integrates an aluminium alloy body offering excellent strength while maintaining low weight.

The slide bearing guide ensures reliable and smooth guidance, making it suitable for complex positioning tasks. Rubber cushioning provides quiet operation and absorbs impact, extending the life of the device.

Operating reliably within temperatures from -10°C to 60°C and handling pressures up to 0.7 Mpa, the MXS12-75 is versatile for various manufacturing, packaging, and assembly line environments. The piston rod has an M5 thread size, enabling compatibility with standard pneumatic fittings.

The compact dimensions of 158mm length, 50mm width, and 32mm height allow seamless integration into machinery with through hole mounting. The maximum piston speed of 500 mm/s supports dynamic process requirements.

This unit weighs 660 grams, making it suitable for applications where light weight pneumatic actuators are preferred. Durable aluminium alloy body construction. Slide bearing for precise guidance and stability. Rubber cushioning for smooth, silent operation.

Double acting operation for controlled forward and return strokes. Supports a max pressure of 0.7 Mpa and speeds of up to 500 mm/s. Compact size and through hole mount compatibility. Wide operating temperature range from -10°C to 60°C.

Ideal for pneumatic automation, assembly, material handling, and packaging industries requiring compact, precise cylinder solutions. Explore more Pneumatic Guided Cylinders on EnvMart to optimize your industrial processes.
