TE Connectivity AMP-LATCH Series Straight Through Hole PCB Header, 40 Contact(s), 2.54 mm Pitch, 2 Row, Shrouded 5103308-8
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | TE Connectivity |
| Orientation | Straight |
| Current | 1A |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | AMP-LATCH |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 40 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.05mm |
Key Features
- Compatible with wire-to-board connector systems for robust PCB interfacing.
- Constructed with thermoplastic housing for durable insulation.
- Copper alloy contacts plated with gold ensure excellent conductivity and corrosion resistance.
- Supports a voltage rating of 250 V and a current rating of 1 A for reliable electrical performance.
- Designed for through-hole mounting with 3.05 mm tail pin length for easy soldering.
- Suitable for operating temperatures from -55°C to 105°C for versatile usage environments.
- Shrouded design enhances protection against accidental short circuits and mechanical damage.
- Standard 2.54 mm pitch and 2-row configuration simplifies integration into standard PCB layouts.
Product Description
TE Connectivity 5103308-8 PCB Header is a precision-engineered connector designed for high reliability in electronic component assemblies. Featuring 40 contacts arranged in two rows at a 2.54 mm pitch, it provides a compact and efficient solution for PCB interfacing in various industrial and commercial applications.
This straight through hole header incorporates a shrouded housing made of thermoplastic material, offering protection to the contacts and ensuring long-term durability in harsh conditions. The contacts themselves are made from copper alloy and plated with gold to deliver superior conductivity and resist corrosion, thus maintaining signal integrity over time.
Rated for 1 A current and 250 V voltage, the header supports typical operating conditions in electronics manufacturing, including operating temperatures ranging from -55°C to 105°C, making it suitable for a wide range of environments.
The 3.05 mm tail pin length facilitates reliable soldering onto printed circuit boards using through-hole mounting techniques. The shrouded design adds an additional layer of mechanical and electrical protection, preventing accidental shorting and enhancing assembly safety.
This product is ideal for use in industrial electronics, manufacturing equipment, laboratory instrumentation, and commercial electronic devices requiring dependable PCB connection interfaces.
Compatible with wire-to-board systems, facilitating easy integration into existing assemblies. Thermoplastic housing offers stability and durability under mechanical stress. Copper alloy contacts with gold plating ensure long-term electrical performance.
Rated for 250 V and 1 A, suitable for a wide range of electronic circuits. Designed for through-hole mounting with standardized pitch and row spacing. Operating temperature range from -55°C to 105°C accommodates diverse application needs.
Shrouded, two-row configuration protects contacts and improves connection security. Choose TE Connectivity 5103308-8 for reliable and efficient PCB header solutions. Explore more products like this in our Electronics & Electricals category at EnvMart.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a voltage rating of 250 V, making it suitable for various electronic circuits.
This model features 40 contacts arranged in two rows.
The current rating is 1 A, ensuring reliable electrical performance in applications.
The pitch size is 2.54 mm, which is standard for many PCB layouts.
The housing is made of thermoplastic, while the contacts are copper alloy plated with gold for enhanced conductivity and corrosion resistance.
The tail pin length is 3.05 mm, designed for easy soldering onto printed circuit boards.
It can operate within a temperature range of -55°C to 105°C, accommodating diverse application needs.
Yes, this model is specifically designed for through-hole mounting.
It is compatible with wire-to-board connector systems, facilitating easy integration into existing assemblies.
The contacts are oriented straight, which is typical for through-hole connectors.
The shrouded design enhances protection against accidental short circuits and mechanical damage, improving connection security.
The country of origin for this product is India.
