Phoenix Contact PTDA 2.5/3-PH-5.0 Series Pluggable Terminal Block, 3-Contact, 5 mm Pitch, 1 Row, 1725510
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 630V |
| Brand | Phoenix Contact |
| Colour | Green |
| Orientation | Right Angle |
| Current | 14A |
| Length | 15mm |
| Model | 1725510 |
| Depth | 16mm |
| Width | 20mm |
| Housing Material | Polyamide |
| Series | PTDA 2.5/3-PH-5.0 |
| Number of Rows | 1 |
| Pitch | 5mm |
| Number of Contacts | 3 |
| Connector Gender | Female |
| Minimum Wire Size mm² | 0.2mm² |
| Maximum Wire Size mm² | 2.5mm² |
| Minimum Wire Size AWG | 24AWG |
| Maximum Wire Size AWG | 12AWG |
| Wire Connection Method | Push-in Spring |
Key Features
- Equipped with 3 female contacts for secure wiring.
- 5 mm pitch ensures compact and efficient PCB footprint.
- Constructed with durable polyamide housing for robust insulation.
- Supports wire sizes from 0.2 mm² to 2.5 mm² (24 AWG to 12 AWG).
- Rated for up to 14 A current at 630 V voltage.
- Features right-angle orientation with push-in spring wire connection method.
- Designed for easy plug-in with release button and optional mechanical coding.
- Compact dimensions with length 15 mm, width 20 mm, and depth 16 mm.
Product Description
Phoenix Contact 1725510 PTDA 2.5/3-PH-5.0 is a pluggable terminal block designed for reliable electrical connections in industrial and electronic applications. It features 3 female contacts arranged in a single row with a 5 mm pitch, ensuring space-saving and efficient PCB layout.
The terminal block supports wire cross sections from 0.2 mm² to 2.5 mm², suitable for AWG sizes 24 to 12. Constructed with a robust polyamide housing, it offers strong insulation and longevity under demanding conditions.
Rated for 14 A at 630 V, this terminal block uses a spring-cage push-in wire connection method, facilitating convenient installation with a release button. The right-angle orientation provides versatility for PCB mounting options.
Equipped with 3 female contacts for secure wiring. 5 mm pitch ensures compact and efficient PCB footprint. Durable polyamide housing for strong insulation. Supports wire sizes 0.2 to 2.5 mm² (24 to 12 AWG). Rated for 14 A current and 630 V voltage.
Right-angle orientation with push-in spring connection. Compact dimensions: 15 mm length, 20 mm width, 16 mm depth. Optional mechanical coding and plug available for customization.
This component is suitable for industrial, electronic, automation, power connector, and PCB construction applications where reliable and compact electrical connectors are required. Its design allows efficient use in control cabinets, manufacturing equipment, and instrumentation.
Set includes one pluggable terminal block with specifications as per series PTDA 2.5/3-PH-5.0. Explore EnvMart for a wide range of industrial electrical connectors and terminal blocks from trusted brands like Phoenix Contact.
Explore more products in our Pluggable Terminal Blocks category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 14 A and a voltage of 630 V.
It supports wire sizes ranging from 0.2 mm² to 2.5 mm², which corresponds to AWG sizes 24 to 12.
The pitch of this terminal block is 5 mm, allowing for a compact PCB footprint.
This terminal block features 3 female contacts arranged in a single row.
It is constructed with durable polyamide housing, providing strong insulation.
This model has a right-angle orientation, which offers versatility for PCB mounting.
The dimensions are 15 mm in length, 20 mm in width, and 16 mm in depth.
It utilizes a push-in spring connection method for easy wiring.
Yes, this model includes optional mechanical coding for customization.
It is designed for use in industrial, electronic, automation, power connector, and PCB construction applications.
The country of origin for this terminal block is India.
This terminal block is part of the PTDA 2.5/3-PH-5.0 series.
