Omron Surface Signal Relay 5V DC Coil 1A DPDT G6JU-2FS-Y DC5
Specifications
| Country of Origin | China |
|---|---|
| Brand | Omron |
| Height | 10mm |
| Length | 10.6mm |
| Model | G6JU-2FS-Y DC5 |
| Width | 5.7mm |
| Mount Type | Surface |
| Contact Material | Gold Plated |
| Series | G6J |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 1A |
| Terminal type | Surface Mount |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 245.5Ω |
| Coil Voltage | 5V dc |
| Switching DC Voltage | 110V dc |
| Switching AC Voltage | 125V ac |
| Coil Power | 100mW |
| Switching Power | 30W |
Key Features
- Ultra-compact size of 5.7mm width, 10.6mm length, and 10mm height.
- Gold plated contacts ensure reliable, low-resistance switching performance.
- Operates over a wide temperature range from -40°C to 85°C.
- Rated for switching voltages up to 125V AC and 110V DC with 30W maximum power.
- Fully sealed construction meeting RoHS compliance and North American Telcordia standards.
- Surface mount terminal type enables easy PCB integration.
- Low coil power consumption of 100mW with coil resistance of 245.5Ω.
- Contact resistance rated at 100mΩ for efficient signal transmission.
Product Description
Omron G6JU-2FS-Y DC5 surface signal relay is an ultra-compact, DPDT contact relay designed with a 5V DC coil, 1A switching current, and gold plated contacts, ideally suited for precise signal switching in electronic and industrial control circuits.
This surface mount relay measures just 5.7mm in width, 10.6mm in length, and 10mm in height, making it perfect for space-constrained PCB layouts and automated machinery requiring small form factor components.
The relay features a fully sealed enclosure ensuring durability and reliable operation across a temperature range of -40°C to 85°C. It complies with RoHS standards and North American Telcordia specifications, including FCC Part 68 impulse withstand voltage tests, ensuring high quality and safety in demanding environments.
With a switching power rating of 30W and the ability to switch voltages up to 125V AC and 110V DC, this relay supports a wide range of low-power signal applications. The coil power consumption is minimal at 100mW, with a coil resistance of 245.5Ω.
Gold plated contacts provide excellent conductivity and low contact resistance of 100mΩ, enhancing signal integrity. The surface mount terminal type simplifies installation in automated assembly lines, ideal for electronics manufacturing and automation control systems.
This relay is widely used in industrial automation, electronic control, signal conditioning, and telecommunications equipment, helping improve production efficiency and ensuring reliable signal switching.
Ultra-compact size enables use in dense PCB layouts. Gold plated contacts ensure reliable signal switching. Wide temperature range supports industrial environments. Compliance with RoHS and Telcordia standards ensures quality and safety.
Low coil power consumption increases system efficiency. Surface mount design supports automated manufacturing. Explore a comprehensive selection of Signal Relays and related components in the Electronics & Electricals category on EnvMart for industrial and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The switching current of this relay is rated at 1A.
This model measures 5.7mm in width, 10.6mm in length, and 10mm in height.
The coil voltage for this relay is 5V DC.
It can switch voltages up to 125V AC and 110V DC.
It features a DPDT (Double Pole Double Throw) contact configuration.
The contact resistance is rated at 100mΩ.
The coil power consumption is minimal at 100mW.
It operates over a wide temperature range from -40°C to 85°C.
It uses a surface mount terminal type, facilitating easy PCB integration.
This relay complies with RoHS standards and North American Telcordia specifications.
The contacts are made of gold plated material, ensuring reliable signal switching.
It is widely used in industrial automation, electronic control, signal conditioning, and telecommunications equipment.
