TE Connectivity AMPLIMITE HDP-20 25 Way Straight 2.76 mm Pitch Through Hole D-Sub Connector with 4 to 40 UNC 3-338315-2

Free Delivery in India | Lowest Global Shipping Charges

TE Connectivity AMPLIMITE HDP-20 25 Way Straight 2.76 mm Pitch Through Hole D-Sub Connector with 4 to 40 UNC 3-338315-2

Name: TE Connectivity AMPLIMITE HDP-20 25 Way Straight 2.76 mm Pitch Through Hole D-Sub Connector with 4 to 40 UNC 3-338315-2
Brand: TE Connectivity
SKU: 210230
Price: 13.17 USD
Availability: InStock



Category D-Sub Connector Brand TE Connectivity Condition New

Specifications

Country of Origin	Poland
Brand	TE Connectivity
Orientation	Straight
Current	6A
Mount Type	Through Hole
Housing Material	Polyethylene Terephthalate
Contact Material	Phosphor Bronze
Series	AMPLIMITE HDP-20
Mounting Hardware	4 to 40 UNC Screw Lock
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Pitch	2.76mm
Contact Plating	Gold over Nickel
Number of Contacts	25
Contact Gender	Female
Connector Gender	Female
Connector Type D	D-Sub

Key Features

The connector features a straight orientation suitable for through-hole mounting.
It includes 4 to 40 UNC screw locks ensuring secure mechanical connections.
Housing is made from durable Polyethylene Terephthalate providing robust insulation.
Phosphor Bronze contacts plated with Gold over Nickel offer excellent electrical conductivity and corrosion resistance.
Operating temperature range spans from -55°C to 105°C for versatile industrial applications.
The pitch between contacts is 2.76 mm, conforming to AMPLIMITE HDP-20 series standards.
Termination type is solder, optimized for PCB mounting.
This D-Sub connector is suitable for various industrial, electronic manufacturing, and power distribution uses.

Product Description

TE Connectivity 3-338315-2 AMPLIMITE HDP-20 25 Way Straight 2.76 mm Pitch Through Hole D-Sub Connector is a high-quality female connector designed for reliable signal and power transmission in demanding industrial and electronic applications. It features a straight orientation and is configured for through-hole mounting on PCBs, making it ideal for robust electronic assemblies in manufacturing and power distribution systems.

The connector incorporates 25 contacts made from phosphor bronze, plated with gold over nickel to ensure excellent conductivity, durability, and resistance to corrosion. Its housing is crafted from Polyethylene Terephthalate, a material known for high insulation properties and mechanical strength, complying with UL 94V-0 flame retardant standards.

Designed to operate between -55°C and 105°C, this connector supports a continuous current of up to 6 amperes. The 2.76 mm pitch between contacts aligns with the AMPLIMITE HDP-20 series, providing compatibility with matching components and mating connectors available separately.

Mechanical security is enhanced through 4 to 40 UNC screw locks, ensuring stable and vibration-resistant connections in electronic devices and machinery. The solder termination type simplifies reliable PCB assembly for both manual and automated soldering processes.

Straight female D-Sub connector with 25 contacts. Through hole mounting suitable for standard PCBs of 1.6 mm thickness. 4 to 40 UNC screw lock hardware for secure fastening. Housing made from black UL 94V-0 rated Polyethylene Terephthalate.

Gold over nickel plated phosphor bronze contacts for corrosion resistance. Operating temperature range from -55°C to 105°C. Solder termination for PCB assembly. Applicable in industrial electronics, power connectors, and automation equipment.

This connector is manufactured in Poland under strict quality controls, assuring performance in various environments including industrial automation, electronic instrumentation, and power management systems.

Explore EnvMart’s extensive range of D-Sub Connectors and related electronic components for all your industrial and manufacturing applications.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The pitch between contacts for this connector is 2.76 mm, conforming to the AMPLIMITE HDP-20 series standards.

This connector supports a maximum continuous current of up to 6 amperes.

The housing is made from Polyethylene Terephthalate, and the contacts are made from phosphor bronze plated with gold over nickel for enhanced conductivity and corrosion resistance.

It operates within a temperature range of -55°C to 105°C, making it suitable for various industrial applications.

This model is designed for through-hole mounting on PCBs, which is ideal for robust electronic assemblies.

The termination type is solder, optimized for reliable PCB assembly.

This D-Sub connector features 25 contacts.

It includes 4 to 40 UNC screw locks to ensure secure mechanical connections.

This connector has female contacts, making it a female D-Sub connector.

This connector is manufactured in Poland under strict quality controls.

It is suitable for various industrial, electronic manufacturing, and power distribution applications.

The housing material complies with UL 94V-0 flame retardant standards, ensuring safety in applications.
