TE Connectivity PIDG Insulated Fork Terminal 12 AWG to 10 AWG M6 Stud Size Nylon Yellow 130491
Specifications
| Country of Origin | Hungary |
|---|---|
| Brand | TE Connectivity |
| Colour | Yellow |
| Model | 130491 |
| Width | 9.5mm |
| Insulation | Insulated |
| Overall Length | 32.1mm |
| Contact Material | Copper |
| Series | PIDG |
| Insulation Material | Nylon |
| Contact Plating | Tin |
| Minimum Wire Size mm² | 2.6mm² |
| Maximum Wire Size mm² | 6.6mm² |
| Minimum Wire Size AWG | 12AWG |
| Maximum Wire Size AWG | 10AWG |
| Stud Size | M6 |
Key Features
- Constructed with high conductivity copper body for excellent electrical performance.
- Features a nylon insulation sleeve in yellow for easy wire size identification.
- Includes tin-plated contacts to resist corrosion and improve connectivity.
- Wire barrel has serrations for maximum contact and tensile strength after crimping.
- Copper sleeve provides improved wire insulation support and prevents wire fraying.
- Funnelled wire entry allows fast and reliable wire insertion during production.
- Suitable for industrial, automotive, aerospace, and control panel wiring applications.
Product Description
TE Connectivity 130491 PIDG Insulated Fork Terminal is engineered for secure and durable electrical connections in various demanding environments. This fork terminal supports wire sizes from 12 AWG to 10 AWG with an M6 stud size and features a yellow nylon insulation sleeve for quick wire gauge identification.
The terminal body is crafted from high conductivity copper to ensure excellent electrical performance, while tin plating on the contact area resists corrosion and enhances connectivity reliability. Serrations inside the wire barrel maximize contact and tensile strength post-crimping, and the copper sleeve surrounding the barrel provides reinforced wire insulation support preventing fraying and mechanical damage.
The funnelled entry design speeds up wire insertion, aiding high-speed production processes. These PIDG (Pre-Insulated Diamond Grip) terminals meet demanding application requirements and are widely used in industrial, automotive, lighting, aerospace, control instruments, and panel box wiring implementations.
High conductivity copper body for superior electrical flow. Yellow nylon insulation sleeve for easy wire size identification and electrical safety. Tin-plated contact area provides long-lasting corrosion resistance. Serrated wire barrel ensures optimal contact and tensile strength.
Copper sleeve enhances insulation support and wire protection. Funnelled wire entry aids rapid and secure wire insertion during crimping. Compatible with a wide variety of wire sizes and industrial applications.
This TE Connectivity Fork Terminal is manufactured in Hungary and provides a reliable solution for wiring in multiple sectors including manufacturing, HVAC, automotive, aerospace, and commercial electrical systems. It is ideal for use in panel boxes, motors, control instruments, and transportation equipment for safety and durability.
Explore EnvMart's range of wire terminals and connectors for superior industrial electrical components and accessories.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal supports wire sizes from 12 AWG to 10 AWG, which corresponds to a minimum wire size of 2.6 mm² and a maximum wire size of 6.6 mm².
The stud size for this insulated fork terminal is M6.
The terminal features a high conductivity copper body, a nylon insulation sleeve, and tin plating on the contact area to resist corrosion.
The overall length of this fork terminal is 32.1 mm.
The width of this terminal is 9.5 mm.
This terminal is insulated with a nylon sleeve, which aids in wire size identification and electrical safety.
The serrated wire barrel maximizes contact and tensile strength after crimping, ensuring a secure connection.
The funnelled wire entry allows for fast and reliable wire insertion, facilitating high-speed production processes.
This terminal is suitable for various applications, including industrial, automotive, aerospace, and control panel wiring.
This terminal is manufactured in Hungary.
The contact area features tin plating, which helps to resist corrosion and enhance connectivity reliability.
This terminal belongs to the PIDG (Pre-Insulated Diamond Grip) series.
