EA Elektro-Automatik Programmable Electronic DC Load EL 9000 DT Series 0 to 600 W, 0/500 V, 0 to 16 A EA-EL 9500-16 DT

EA Elektro-Automatik EA-EL 9500-16 DT Programmable Electronic DC Load from the EL 9000 DT Series offers precise load simulation capabilities for testing and measurement applications. It operates over a power range from 0 to 600 W, voltage up to 500 V, and current up to 16 A, suitable for laboratory, educational, workshop, and industrial environments.

The device supports four regulation modes: constant voltage (CV), constant current (CC), constant power (CP), and constant resistance (CR), providing versatile testing flexibility. A fast microprocessor ensures rapid response and precise control, enhanced by the ARM processor hardware control.

An intuitive multilingual color TFT touchscreen panel enables straightforward manual operation, similar to modern smart devices. The integrated true function generator supports standard waveform types - sine, rectangle, triangle - and customizable arbitrary functions, making it well-suited for dynamic load testing.

Featuring USB and Ethernet interfaces as standard, the load allows easy integration into test systems and remote control via SCPI and Modbus RTU protocols. Adjustable protection mechanisms including over-voltage protection (OVP), over-current protection (OCP), and over-power protection (OPP) safeguard both the device and the test components.

The compact 2U rack mount form factor, combined with a carrying handle and tilt stand, offers practical portability and easy installation in testing racks or benches. Supports four operating modes: constant voltage, constant current, constant power, and constant resistance.

Equipped with USB and Ethernet interfaces for flexible connectivity. Features a multilingual color TFT touch panel for intuitive manual control. Includes a true function generator with sine, rectangle, triangle, and arbitrary waveforms.

Provides adjustable protections such as over-voltage, over-current, and over-power. Compact 2U rack size suitable for bench mounting and portable use. Compatible with SCPI and Modbus RTU protocols and supported by control software for Windows.

Manufactured in Germany with RoHS compliance.

This electronic DC load is ideal for industrial, laboratory, educational, and manufacturing test systems requiring precise programmable load conditions. The EL 9000 DT Series enables efficient evaluation of power supplies, batteries, and other DC sources.
