TDK-Lambda DRL-10 Switched Mode DIN Rail Power Supply 264V AC Input 12V DC, 840 mA Output 10W DRL10-12-1

Free Delivery in India | Lowest Global Shipping Charges

TDK-Lambda DRL-10 Switched Mode DIN Rail Power Supply 264V AC Input 12V DC, 840 mA Output 10W DRL10-12-1

Name: TDK-Lambda DRL-10 Switched Mode DIN Rail Power Supply 264V AC Input 12V DC, 840 mA Output 10W DRL10-12-1
Brand: TDK-Lambda
SKU: 208201



Category DIN Rail Power Supplies Brand TDK-Lambda Condition New

Specifications

Country of Origin	China
Brand	TDK-Lambda
Power	10W
Efficiency	85%
Height	91mm
Model	DRL10-12-1
Depth	55.6mm
Width	18mm
Series	DRL-10
Output Current	840mA
Maximum Operating Temperature	71°C
Sub Type	Switched Mode
Minimum Operating Temperature	-20°C
Number of outputs	1
Maximum Input Voltage	264V ac
Electrical Phase	1
Maximum Output Voltage	12V dc
Minimum Input Voltage	85V ac

Key Features

Provides a reliable low profile DIN rail mounting power supply solution.
Operates with universal AC input voltage from 85V to 264V AC.
1 output delivering 12V DC at 840 mA for up to 10 watts of power.
High efficiency of 85% ensures low energy losses during operation.
Wide operating temperature range from -20°C to 71°C for industrial applications.
Safety class II double insulation eliminates earth connection requirement.
Complies with UL 60950-1, UL 1310, UL 508, and IEC 60068 standards.
Compact dimensions of 91mm height, 18mm width, and 55.6mm depth save installation space.

Product Description

TDK-Lambda DRL10-12-1 is a high-quality switched mode DIN rail power supply designed for industrial and building automation environments. It features a universal AC input voltage range of 85V to 264V AC and provides a regulated 12V DC output at 840 mA with a power rating of 10 watts. The compact low-profile design allows easy installation within control panels and electrical enclosures.

This DRL-10 series power supply offers high efficiency at 85%, reducing heat generation and energy consumption. It operates reliably across a broad temperature range from -20°C to 71°C, ensuring robust performance in demanding conditions.

The device includes safety class II insulation, removing the need for earth grounding, while complying with rigorous UL and IEC standards including UL 60950-1, UL 1310, UL 508, and IEC 60068-2-27/6. Its single output with constant voltage and current supports NEC class 2 applications.

With dimensions measuring 91mm in height, 18mm in width, and 55.6mm in depth, it conserves panel space and is suited for applications such as building control systems, security and surveillance, climate controls, smart home installations, and renewable energy projects.

The DRL10-12-1 brings reliable and efficient power delivery with safety certifications tailored for industrial use cases, making it a preferred solution in electrical power supply requirements.

Provides a reliable low profile DIN rail mounting power supply solution. Operates with universal AC input voltage from 85V to 264V AC. 1 output delivering 12V DC at 840 mA for up to 10 watts of power. High efficiency of 85% ensures low energy losses during operation.

Wide operating temperature range from -20°C to 71°C for industrial applications. Safety class II double insulation eliminates earth connection requirement. Complies with UL 60950-1, UL 1310, UL 508, and IEC 60068 standards.

Compact dimensions of 91mm height, 18mm width, and 55.6mm depth save installation space. Ideal for building automation, security systems, climate controls, and renewable energy setups.
